Textiles Upf Ultraviolet Transmittance Tester - China

The textiles UPF Ultraviolet transmittance tester is used to determine the UV transmittance and anti-ultraviolet performance of textiles.

You can directly obtain the UV protection factor of textiles UPF.

1 - BS 7914：1998 Method of test for penetration of erythemally weighted solar ultraviolet radiation through clothing fabrics.

2 - AS/NZS 4399：1996 Sun protective clothing- Evaluation and classification.

3 - AATCC 183 Transmittance or blocking of erythemally weighted ultraviolet radiation through fabrics.

4 - BS EN 13758-1 Textiles - Solar UV protective properties-Part1: Method of test for apparel fabrics.

5 - GB/T18830 Textiles—Evaluation for solar ultraviolet radiation protective properties.

Items Parameters

Transmittance 0~100%±0.01％

UPF 0~100

Wavelength Range 280-400nm±0.5nm

Wavelength repeatability 0.25nm

Date break 1nm-5nm, adjustable

Slit width ≤5nm

Optical system 0/d

Sample beam diameter 10mm

Power AC220V50 Hz 100W

Dimension 285×500×500mm

Weight 20kg
