Xds-5bf Research Level Inverted Fluorescence Microscope - China

Model

XSD-5B

XSD-5BF

Optical

System

Infinity NIS plan Semi-Apo optical system

Eyepiece

High eye-point plan eyepiece PL10X/22, field of view: 22mm.

High eye-point plan eyepiece PL10X/25, field of view: 25mm

High eye-point plan eyepiece PL12.5X/17.5, field of view: 17.5mm

High eye-point plan eyepiece PL15X/16, field of view: 16mm

High eye-point plan eyepiece PL20X/12, field of view: 12mm

Objective

N-IPLAN PH PLAN Semi-Apo lens 4X, 10X, 20X, 40X

Nosepiece

Revolving sixtuple nosepiece（with DIC slot）

Viewing Head

45°inclined trinocular head(with Bertrand lens)

interpupillary distance range: 47-78mm.

45°inclined binocular tilting head interpupillary distance range: 47-78mm.

Stage

Three layer mechanical stage, moving range 130X85mm, flexible knob,

can fix different small size stage on the top for different applications

Focusing

adjustment

Coaxial focus system with up-limited and tension adjustment.

Coarse range: 9mm(up 2mm, down 7mm), coarse focus 2mm one circle,

fine focus: 0.2mm one circle.

Holder

Teraseki holder（φ38mm and φ54mm）

Middle zoom

1X, 1.5X

Condenser

N.A.0.55 long working distance turret type condenser, WD 26mm,

and fix with six different device: PH, DIC, bright field.

Main body

interface

Turret type interface switch(left interface, right interface, eyepiece viewing

switch), beam splitting ratio: left side/100: 0; right side/80: 20; optional: 1: 100

Observation

Method

Bright field, dark field,

phase contrast, DIC

Bright field, dark field,

phase contrast, DIC, fluorescence

Transmitting

Illumination

12V/100W halogen lamp kohler illumination, LED optional

Reflecting

Illumination

---

100W mercury lamp

With max 6 fluorescent cube holder turret

type, center able iris diaphragm and field

diaphragm, three hole filter slide
