Heavy Galvanized Welded Gabion Baskets And Mattress For Protection Project - China

Heavy Galvanized Welded Gabion Baskets And Mattress For Protection Project Gabion box is basket or mesh roll made of twisted hexagonal wire Mesh, Gabion box is filled with rock at the project site to form flexible, permeable, monolithic structures such as retaining walls, channel linings and weirs for erosion control projects.

GABIONS(Higher than 1m in height) andMATTRESSES(Less than 1m in height) consist of rectangular units, fabricated from a double-twisted hexagonal mesh.

Filled with stones, gabions become large, flexible and permeable elements from which a broad range of structures may be built.

Gabions and mattresses are widely used for hydraulic and geo- technical control such as retaining walls, riverbank protections, weirs, channel linings etc.

Specification: Standardsizesinmesh80mmx1 00mmnominal, wirediameter2.7mm, Heavilyzincgalvanised wireorGalfancoatedwitha95 %Zinc+5%AluminiumAlloy.

- - - - Length(m) | width(m) | height(m) | diaphragm | volume | tolerance | 2 | 1 | 0.3 | 1 | 0.6 | Length+/-3% Width+/-5% Height+/-5% | 3 | 1 | 0.3 | 2 | 0.9 | 4 | 1 | 0.3 | 3 | 1.2 | 2 | 1 | 0.5 | 1 | 1 | 3 | 1 | 0.5 | 2 | 1.5 | 4 | 1 | 0.5 | 3 | 2 | 1 | 1 | 0.5 | 0 | 1 | 1.5 | 1 | 1 | 0 | 1.5 | 2 | 1 | 1 | 1 | 2 | 3 | 1 | 1 | 2 | 3 | 3 | 2 | 1 | 2 | 6 | 4 | 1 | 1 | 3 | 4 | - - - - Engineering Applications: Control and guide of water or flood Preventing of rock breaking Rock fall protection Water and soil protection Bridge protection Strengthening structure of soil Protection engineering of seaside area Port project Keep off dust wall Roadway protection.

In Konson's workshop:

Company Contact:

• Posted By: Konson Industrial Co., Ltd.

• Phone: 86-0510-83552045

• Address: YANGSHI INDUSTRIAL ZONE A-2, WUXI, JIANGSU, CHINA, Wuxi , Jiangsu , China

• Email:

• Website: http://www.gabionmachines.com/

• Business Description: Founded in May of 1999，KONSON INDUSTRIAL CO., LTD. is the earliest company specialized in Gabion boxes, reno mattress, Hexagonal Wire Netting, Gabion Retaining Wall, Gabion Machine and Gabion Production Line in China.
