Full Ac Motor Mini Electric Forklift Truck 1000kg Capacity 920mm Fork Lenghth - China

mini electric forklift 1000kg capacity with full AC motor920mm fork lenghth 1 ton electric forklift Feature 1 - This electric forklift truck not only has excellent operability, comfortable and safe, and reliable performance with waterproof.

In addition, it can also significantly more comfortable and more versatility.

2 - Designed to work in the rain, electric forklift can be used in various kinds of wet and dry environments.

3 - As the model of waterproof level, this model can really do its work in a vertical or 60 degree angle rainfall environment.

4 - All control devices in the car are security settings into the weight balance in the rear of the vehicle, taking into account all the possible uses of water flow, we provide some rubber bands to prevent the water in the steam into the interior of the vehicle body.

The specification of 1 ton electric forklfit - - - - Features | 1 | Manufacturer | | | LTMA | 2 | Model | | | FB10 | 3 | Load capacity | | kg | 1000 | 4 | Load center | | mm | 500 | 5 | Power unit | | Battery | 6 | Operator type | | | Driver/seat | 7 | Tire type | Front/rear | | Air tires | 8 | Wheel | Number Front/rear | 2X/2 | Dimension | 9 | Max.

lifting height | | mm | 3000 | 10 | Free lift | | mm | 155 | 11 | Fork size | L*W*T | mm | 920*120*35 | 12 | Tilt range | Mast forward/backward | deg | 6/2 | 13 | Overall length(without fork) | | mm | 2150 | 14 | Total width | | mm | 1090 | 15 | Mast height (fork lowering) | | mm | 1995 | 16 | Overall height fork raised | With backrest | mm | 3945 | 17 | Height to head guard | | mm | 2170 | 18 | Turning radius(outside) | | mm | 1950 | 19 | Front face of fork to front axle | | mm | 375 | 20 | Min.

right angle stacking aisle | not add load length&clearence | mm | 1770 | Performance | 21 | Speed | Max Travelling full/no load | km/h | 14/16 | 22 | Lifting full load | mm/s | 350 | 23 | Lifting no load | mm/s | 530 | 25 | Gradeability | full load | % | 15 | Weight | 26 | Truck weight | | kg | 3070 | 27 | Weight distribution | Full load front/rear | kg | 3635/555 | 28 | No load front/rear | kg | 1110/1580 | Frame | 29 | Tires | Number | front/rear | 2/2 | 30 | Model | front axle | 6.00-9-10-10PR | 31 | rear axle | 16x6-8-10PR | 32 | Wheelbase | | mm | 1380 | 33 | Tread | Front/rear | mm | 910/900 | 34 | Ground clearance | At lowest point(mast) | mm | 115 | Frame | mm | 95 | 35 | Brake | Service brake | | Hydraulic-foot peda | Parking brake | | Mechanical lever | Electric motor and controller | 36 | Battery | Voltage/capacity | V/AH/5hr | 48V-400 | 37 | Weight (standard) | kg | 735 | 38 | Electric motor | Driving motor | kw/60min | 8 | 39 | Hydraulic driving motor | kw/5min | 8.2 | 40 | Control type | Electric driving | 1 | 41 | Operating pressure | Hydraulic system pressure | kg/cm | 145 | NOTE: 1 - Drving AC choppedwave control mode /lifting AC voltage control mode | - - - - After-sale service Nowadays we have been sell more than 100 countries.

All the products of LTMA supplied with one year or 2000 working hours (which occurs first) period quality warranty.

Detail clauses and policies please see to our website and products quality certificate.
