Mineral Stirred Tank Agitation Tube Settler Clarifier High Capacity - China

Mineral Stirred Tank Agitation Tube Settler Clarifier High Capacity The mining used agitating tank is applied to mix round all kinds of ore slurry.

Mainly used for A variety of metallic minerals in the flotation beneficiation process or re-election before the slurry mixing, Making the beneficiation reagent and ore slurry mixed well-proportioned, it also can be used for other non-metallic slurry mixing.

It has been widely used in chemical and construction industry, cyanide chemical plant, sewage treatment plant, and coal plant etc.

Effective volume: 0.26-30m Power range: 1.1-22kw Processible materials: metals and non-metals.

Application range: ore beneficiation, construction materials, road and railway construction.

Advantages: high capacity, strong mixing capacity and high working efficiency.

How Mineral Mixing Tank works? This equipment is mainly consist of cell body, vertical axis, Cycle barrel transmission frame Motor and other components, through the vee belt to drive Vertical axis side pulley by electric motor, the bottom of the vertical axis Promote the impeller rotation, mixing the ore slurry to achieve the aim of well-distributed.

The using concentration cannot be greater than 30 %( by weight), and the particle size of the fixed component is less than 1mm.

the form of it is the flat bottomed bucket radiation cycle with the spiral impeller mechanical agitation.

Features of High Density Mineral Stirring Tank Compact structure, good seal, and feed port settings the block gray board, to prevent the mist playing.

Stir mixing blades fanned when stirred media contact area.

The nozzle row set, more water is uniform and can adjust.

Leftover ash and low settings box at the bottom of the watershed to ensure that the equipment no dead ends.

Mine mixing tube equipment advanced performance, the quality of the finished product is stable, stir rapid discharge.

Remarks of Agitation Tank Fasten the pump bolts before using it, rotate the pump shaft wheel to check if it is flexible, run and turn on the stirring tank; Wearing parts: impeller and stator; Clear the inside of the mixer or stirring tank, especially in winter, to prolong its service life.

- - - -

Specification | Chute inner dimension | Effective cubage | Mixer | Motor | Weight (kg) | | Diameter (mm) | Depth | (m3) | Diameter(mm) | Rotate speed (r/min) | Model | Power (kw) | | | | (mm) | | | | | | | XB-750 | 750 | 750 | 0.26 | 240 | 530 | Y90S-4 | 1.1 | 228 | XB-1000 | 1000 | 1000 | 0.58 | 240 | 530 | Y90L-4 | 1.5 | 436 | XB-1200 | 1200 | 1200 | 1.14 | 400 | 320 | Y100L2-4 | 3 | 765 | XB-1500 | 1500 | 1500 | 2.2 | 400 | 320 | Y100L2-4 | 3 | 1083 | XB-2000 | 2000 | 2000 | 5.46 | 550 | 230 | Y132M2-6 | 5.5 | 1671 | XB-2500 | 2500 | 2500 | 11.2 | 650 | 200 | Y160L-6 | 11 | 3438 | XB-3000 | 3000 | 3000 | 19.1 | 700 | 210 | Y225S-8 | 18.5 | 4613 | XB-3500 | 3500 | 3500 | 30 | 850 | 230 | Y225M-8 | 22 | 7110 | - - - -
