N04400 Monel 400 Nickel Clad Tubesheet For Anti Corrosion - China
price: check with company for price
N04400 Monel 400 Nickel Clad Tubesheet for Anti-corrosion Description: Clad plates provide an economical solution for chemical processing.
Explosion welding is a solid state joining process in which explosive energy is used to propel the component metal parts together to form a metallurgical bond.
At the point of impact of the two components, a thin layer is stripped from both colliding surfaces and is ejected as a molten metal jet.
This jet contains the surface contaminants and oxides that would otherwise prevent bonding.
The two surfaces are in intimate contact under extreme pressure enabling the bond to be formed.
Table for available type of Nickel alloy clad plates: - - - - Product Names: | Nickel & Nickel Alloy Clad Plate/Sheet, Nickel & Nickel Alloy Clad Plate/ Tube Plate | Production Codes: | ASTM B265, ASME SB265, DIN, BS, JIS, GB/T, ISO, etc.
| Nickel Grades: | ASME B127, ASME B162, ASME A164 UNS N02200 (Ni200), N04400 (Monel 400), N06600 (Inconel 600), N08800 (Incoloy 800), N08825 (Incoloy 825), N10276 (C276), N10675 (B-3), N06022 (C22), N06059 (C59), N06200 (C2000), N08020 (20 Alloy) | Form | Description | Base Layer | Base Layer Grade | Maximum Size | Clad Plate | Nickel / Carbon Steel Clad | Carbon steel plate and forging | SA516 Gr.
60(N), Gr.
70(N), SA387 Gr.
11, Gr.
22, SA266, SA350, etc.
| (1.5~14)/(2~200) x W(max W 4110) x L(max L 7000) | Nickel / Copper (Naval Brass) Clad | Copper, Naval Brass | C10100, C10200, C11000, C26200, C28000, C46400, C70600, C71500, etc.
| (1.5~14)/(2~100) x W(max W 2100) x L(max L 6000) | Nickel / Aluminum Clad | Aluminum | A1050, A1060, A1070, A1100, A5052, etc.
| (1.5~14)/(2~50) x W(max W 1500) x L (max L 4000) | Titanium / Nickel Clad | Nickel and its alloy | N02200, Monel 400, Inconel 600, Incoloy 800, 825, C276, C22, etc | (1.5~14)/(2~50) x W(max W 2000) x L (max L 5000) | Nickel / Carbon Steel / Nickel Clad | Carbon steel plate and forging | SA516 Gr.
60(N), Gr.
70(N), SA387 Gr.
11, Gr.
22, SA266, SA350, etc.
| (1.5~14)/(6~200)/(2~10) x W(max W 3000) x L(max L 6000) | Nickel / Copper / Nickel Clad | Copper, Naval Brass | C10100, C10200, C11000, C26200, C28000, C46400, C70600, C71500, etc.
| (1.5~14)/(6~100) x W(max W 2100) x L(max L 6000) | Nickel / Carbon Steel / Stainless Steel Clad | Carbon steel plate and forging | SA516 Gr.
60(N), Gr.
70(N), SA387 Gr.
11, Gr.
22, SA266, SA350, etc.
| (1.5~14)/(6~200)/(1.5~10) x W(max W 4110) x L(max L 7000) | Duplex, Stainless Steel & their forgings | 304L, 316L, 316Ti, 321, 317L, 310S, 410S, 904L, 1805, 2205, 2507, Al6XN, 254sMo, etc.
| Aluminum / Nickel / Carbon Steel Clad | Aluminum | A1050, A1060, A1070, A1100, A5052, etc.
| (1.5~40)/(1-5)/(6~200) x W(max W 1000) x L(max L 1000) | Carbon steel plate and forging | SA516 Gr.
60(N), Gr.
70(N), SA387 Gr.
11, Gr.
22, SA266, SA350, etc.
| Aluminum / Nickel / Copper Clad | Aluminum | A1050, A1060, A1070, A1100, A5052, etc.
| (1-10)/(1-5)/(6-100) x W(max W 1000) x L(max L 1000) | Copper, Naval Brass | C10100, C10200, C11000, C26200, C28000, C46400, C70600, C71500, etc.
| Application: Petro-chemical, Vacuum Salt Industry, Chlor-alkali, Metallurgical, Food, Light Industry, Medicine, Auto Industry, Electrolytic Aluminum, Fertilizer, Kitchenware, Power Industry, Building Materials, Electrolysis Industry, Hydrometallurgy etc.
| - - - - Product advantage: -Clad plates provide an economical solution for chemical processing; - Corrosion resistance; -Technical consulting on material, thickness suggestion, welding, NDE, etc.
