Polycarbonate Solid Sheet Sy 1910 Clear - Taiwan

Sun Asia brand High Performance PC (polycarbonate) Solid sheet with high concentration of Anti-UV coating on the surface with ten years warranty.

Approved chemical construction materials testing and national industry standards.

Product Features：

Anti-ultraviolet, Anti-aging ─ Coating anti-UV resin on the surface of weathering weak PC sheet by Co-extrusion process.

There are high concentration of anti-UV coating on surface, which could block ultraviolet through and prevent yellowing and extend the lifetime of panel and keep excellent transparency for long time.

Flame Resistance ─ PC sheet have excellent flame resistance up to B1 grade by national lab.

Selfignition temperature is 630ºC.

Would not contribute to the spread of fire when burning, No smoke and No poisonous gases.

Self-extinguishing Away from the fire.

Light and Environment Friendly and Unbreakable ─ The 10mm panel lighter 52% than 10mm tempered glass.

Easy and durable for construction.

Impact Resistance ─ The PC sheet with excellent impact resistance from -40ºC to +120ºC, exposing outside for a long time.

Light Transmission ─ The light transmission of clear PC Solid sheet could up to 88%.

Also clear PC Hollow sheet’s could up to 80%.

The transparency will not be bad after be used.

The PC Solid sheet with color could prevent the strongest part of the sun's rays through, so transfer the light into soft.

Shape Stability ─ The PC sheet would remained good impact resistance and rigidity after long time in a complex extreme temperature conditions.

Product reference：

Item Color Reference code

Polycarbonate Solid sheet Clear

SY1910

Polycarbonate Solid sheet Light Green SY1930

Polycarbonate Solid sheet Brown SY1920

Polycarbonate Solid sheet Gray SY1950

Polycarbonate Solid sheet Green SY1940

Product Comparison： ◎Best ○Good △Standard ※For reference only

Item High Performance PC Solid Sheet

Clear Gray Brown Green Light Green



Light Transmittance 88.72% 17.62% 37.05% 63.63% 46.63%

Insulator Factor 6.51% 14.28% 14.03% 13.53% 14.28%

UV Absorption ◎ About 100% ◎ About 100% ◎ About 100% ◎ About 100% ◎ About 100%

Yellowness Within 10 years △6 Within 10 years △6 Within 10 years △6 Within 10 years △6 Within 10 years △6 Note：1 - Above mentioned are basis result of 3mm thickness.

2 - Color to refer to actual finish product.

3 - The Yellowness depends on grade of Anti-UV absorber.

Product specifications：

Thickness (mm) Width (m/m) Length (m/m) Surface Color Minimum Bending Radius (mm)

1.8 ~ 6 600 ~ 2050 Customize Flat As Sample

Color / Customize Cold bent：Thickness x 180

times or heat bent

7 ~ 8 600 ~ 1220

9 ~ 10 600 ~ 1220 Only thermoplastic

bending is acceptableApplications :

Roofing, Skylight, Canopies, Ceiling covering, Advertising board, Signage, Impact resistant cover, Safety and security glazing, Barrel vault roofing, Balcony cladding, Sound proof walls, Vehicle instrument board, Bicycle sun shield, Pool enclosure, Shower
