Automatic Hot Fill Equipmentrinsing Capping Multi Founction Dcgf32 32 10 - China

DCGF32/32/10hotr rinsing, filling, capping3IN1 machine Description: This series machine is adopt block bottle-neck hanging work state design, and be adopt filling valve rise-drop design, It's be satisfy for 95 degree hereinafter hot filling technology demand.

It's adopt person-machine interface touch-screen, PLC, transducer etc advanced control technology.

It's osculant the drink material parts are adopt the SUS304 stainless steel, The machine main motor, reducer, mostly axletree, pressurize parts and electricity ware element, gas drive element etc are adopt famous international manufactruer products.

Feature: 1 The automation is high.

It is good equipment for choosing hot drink filling machine.

2 - The design is scientific and reasonable.

Its appearance is beautiful.

Its operation and maintenance is convenient.

3 - The machine integrates washing, filling, capping together.

4 - This RCGF Series 3-in-1 Set For Bottle Juice Washing, Filling And Capping Machine is used in hot filling and sealing of green tea, black tea, wulong tea and fruit juice drink.

5 - This RCGF Series 3-in-1 Set For Bottle Juice Washing, Filling And Capping Machine for filling tea and fruit juice drink.

Specifications: 1 - Capacity: 250--1000ml (can be filled by one machine) 2 - Output: 1800-2500 cartons/hour 3 - Packing material: Cardboard carton / aluminium foil carton 4 - Shelf life: Depend on different product and different process 5 - Capping: With capping (Optional) 6 - Filling temperature: Hot filling: 88-92 degC / cold filling: 2-50 degC 7 - Overall power: 25KW (three phases of electricity) 8 - Compressed air pressure: 1.0-1.4 Mpa, Flow rate: 1.4-2M3/min, without oil, water and dust 9 - Cooling water: Flow volume: 40L/ min Temperature: &le: 30 degC 10 - Size: (L*W*H): 3.7m*1.6m*2.8m 11 - Net Weight: 3500kg 12 - Installation requirement: Any smooth floor, such as cement, floor tile, plastic ground, etc.

Do not need to make angle.

Details: 1 - Hot sale automatic juice glass bottle filling machine is used to fill juice, tea and other non-gas beverage.

2 - All the machine part which contact with liquid is high quality stainless steel 304 - The relative fittings are from international famous brand.

3 - The automatic juice glass bottle filling machine is equipped with suspension type air conveyor and frequency control of motor speed.

4 - This machine is comprised of rinsing, filling and capping system.

Rinsing: grip the bottle neck, rotate filling plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely.

Filling: hot filling with holding bottle neck; the special backflow type of the filling valve can avoid leakage after filling and also control liquid level accurately.

Capping: magnetic torque bottle holding type can minimize the cap damage rate and make the capping performance the best.

5 This machine owns the reasonable, stable and safe design.

Under the condition that the bottle neck size is the same, only the output star wheel needs to be changed if bottles are different.

It improves the efficiency a lot.

6 - We are the automatic juice glass bottle filling machine manufacturer from China.
