DCGF 32-32-10 hot filling machine Description: 1 - The machine is mainly used for filling carbonated drink.

It combines rinsing and filling and capping as one automatic body suitable for PET or other plastic bottles.

The iso-pressure (iso-barometric) filling technology is adopted enabling it to fill more efficiently and more stably with more output than the machine of the same level from others.

2 - Besides using photo-electronic detectors to detect the running of every important sub-process, it employs PLC from OMRON for automatic control of the whole process and new type air-channel for bottle-loading featuring speediness and damage-free of bottle.

The handing-over of bottles between two linking structures is fulfilled by applying clamping-bottle-neck method.

For bottle of different shape only a few parts need to be changed and the substituting is simple, which shows the machine is of good adaptability.

3 - High automation and easy operation make it an ideal option for beverage companies.

Feature: 1 - The DCGF carbonated drink filling machine For gas drink, as coca cola 2 - It is Suit for 300ml-2000ml bottle 3 - It is washing filling capping 3 in 1 machine full automatic 4 - Our company have passed CE, ISO certification Specification: - - - - Model | DCGF 12-12-5 | DCGF 18-18-6 | DCGF 24-24-8 | DCGF 32-32-10 | DCGF 40-40-10 | DCGF 50-50-12 | Bottle Dates | Max Height: 320mm Max Dia: 50-110mm 28PCO Screw Capper | Rinser No | 12 | 18 | 24 | 32 | 40 | 50 | Filler No | 12 | 18 | 24 | 32 | 40 | 50 | Capper No | 5 | 6 | 8 | 10 | 10 | 12 | Capacity | 2000b/h | 3000-4000 b/h | 5000-6000 b/h | 80000b/h | 12000b/h | 15000b/h | Power (kw) | 3.5 | 4.2 | 5.4 | 7.8 | 8.3 | 9.6 | Overall size | 2450*1800* 2400 | 2650*1900* 2400 | 2900*2100* 2400 | 4100*2400* 2400 | 4550*2650* 2400 | 5450*3210* 2400 | you also can customize the size according to your requirement, here is only part of sample.

| - - - -
