Rinsing Sealing Automatic Water Bottle Filling Machinece Iso9001 Certificated - China

CGF18-18-6 automatic water rinsing, filling, sealing machine with CE ISO9001 certificate Description: The water filling machine can carry out washing bottle, filling and capping one machine.

The whole machine designing is reasonable.

The appearance is beautiful and the maintenance is convenient.

It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and easier.

The main machine adopts advanced PLC control technology.

The key electric elements are adopting international famous products.

Thewater filling machine applies bottle handling technical and the filling valves go up-down when filling, which make sure the bottle filling goes stable, reliable during high speed.

The bottle handling technical also make the different bottle changing easily without changing too many accessories.

Features: Man-machine interface control, easy to operate Automatic tearing, preforming 1 - hopper-type preform warehouse automatic row billet stable and reliable 2 - according to the stock automatically control the stock 3 - closed, no pollution 4 - Heating system is perfect 5 - revolution, rotation system is stable 6 - heating blank tube heated evenly, easy blowing system 7less energy consumption, the various sections of the tube temperature can be easily adjusted according to need 8 - Furnace infrared lamp optional circulating air cooling system 9 - heating light box with automatic feedback, closed-loop regulation system, the proportion of automatic constant power output, free from voltage fluctuations Specification 1, Model: CGF18-18-6 type 2, the number of stations: flushing 18, filling 18, cover 6 3, rated production capacity: 6000 bottles / hour (600ml / bottle) 4, air pressure: 0.7MPa 5, gas consumption: 0.5M3 / min 6, red bottle water pressure: 0.2-0.25 MPa 7, red bottle water consumption: 0.5 tons / hour 8, filling method: atmospheric filling 9, the rated voltage: 380V 10, Dimensions: 2500 1900 2500 (L W H) 11, equipment weight: 2500Kg Details 1 - specially desgined and manufactured for the high-speed packing requirements of drink(pure water, beverage, fruit juice and milk product).

2 - during the product froward conveying process, it can automatically group into package, so as to save time and enhance packing efficiency.

3 - adopt the programmable logic controller(PLC), which can carry out the automatically work flow.

4 - use the isothermal sealing cutter, its surface spray TEFLON COAT, the seal is even and secure.

5 - touch-screen operating panel with user-frendly interface and absolutely an easy-to-operate machine.

6 - without bottom support, it can suit for different bottle neck bottle combination.

7 - the ideal model of middle-speed heat-shrinking packager in the domestic market.

easy-operate .
