Ac Powered Explosion Proof Forklift 1980mm Turning Radius With Anti Friction Brake - China

AC powered explosion-proof electric forklift with explosion-proof mark: Exsd II BT4 offer high safety functions Quick Details: Capacity: 2000kg Lifting height: 3000-5600mm Fork dimensions: 40/120/1070mm Fork carriage width: 980mm Aisle width for pallets 1000*1200 crossways: 3600mm Aisle width for pallets 800*1200 lengthways: 3400mm Turning radius: 1980mm Travel speed, laden/unladen: 11/11.5km/h Battery: 48V540AH - Explosion-proof special power device - Explosion-proof lights ExsdllBT4 (on each side) of Industrial - Explosion-proof electric horn of Industrial trucks ExdllBT4 truck ExdllBT4 - Explosion-proof direction - Explosion-proof travelling switch (two) light (on each side) of EXedllCT6 Industrial trucks ExdllBT4 Advantages: # Side-put lifting cylinders and chains offer Wide-view visibility.

# AC Variable-frequency speed control technology, greatly improved the reliability and safety.

# Advanced H - drive axle, low center of gravity design, with stable turning.

# With regenerative braking system, ramp soft starting, reverse braking system and other protection setting.

Improve the safety under the hazardous environments.

# Charger connection and emergency switch have an inter-lock system, safe for charging.

# Special explosion-proof sealed VBS batteries conform to UK BS directive.

# With anti-friction flameproof brake plate.

# With alloy copper plated truck back body and forks.

- - - - SPECIFICATIONS | Model | | CPD20Ex | Explosion-proof | | Exd mbs II BT4 Gb/DIP A21 TA, T4 | Operation type | | seat | Load capacity | kg | 2000 | Load center distance | mm | 500 | Load distance, centre of drive axle to fork | mm | 428 | Wheelbase | mm | 1460 | Axle loading, laden front/rear | kg | 4820/860 | Axle loading, unladen front/rear | kg | 1760/1920 | Tyre size, front | mm | 6.50-10-10PR Ex | Tyre size, rear | mm | 5.00-8-8PR Ex | Tread, front | mm | 970 | Tread, rear | mm | 920 | Tilt of mast/fork carriage forward/backward | Grad | 3-6 | Height, mast lowered | mm | 2090-2450 | Max.

lifting height | mm | 3000-5600 | Height, mast extended | mm | 4067-6667 | Height of overhead guard(cabin) | mm | 1992 | Seat height | mm | 980 | Coupling height | mm | 480 | Overall length | mm | 3300 | Length to face of forks | mm | 2160 | Overall width | mm | 1140 | Fork dimensions | mm | 40/120/1070 | Fork carriage width | mm | 980 | Ground clearance, laden, below mast | mm | 100 | Ground clearance, centre of wheelbase | mm | 130 | Aisle width for pallets 1000*1200 crossways | mm | 3600 | Aisle width for pallets 800*1200 lengthways | mm | 3400 | Turning radius | mm | 1980 | Travel speed, laden/unladen | km/h | 11/11.5 | Lift speed, laden/unladen | mm/s | 260/300 | Lowering speed, laden/unladen | mm/s | 600 | Max.

gradeability, laden/unladen | % | 10/15 | Service brake | | mechanical/hydraulic | Battery | V/Ah | 48/540 | Type of drive control | | AC | Sound level at the driver's ear acc.

to DIN 12053 | dB(A) | 68 | Service weight | kg | 3680 | - - - - Our Ex AC type electric forklift is approved with Explosion-proof mark: Exd mbs II BT4 Gb/DIP A21 TA.

T4 explosion-proof equipment for Category 2G, applicable to Zone I and Zone II which may have explosive gas environment.

Offer high safety functions according to international standards.

Remark: The data is based on the lifting height 3000mm; lifting height from 3000mm to 5600mm are available.
