Simple 2 Ton Electric Pallet Truck Tiller Head Shockproof For Warehouse - China

Small turning radius 2000kg electric pallet truck with Germany FREI tiller head Quick details: Model: Electric pallet truck Stand on type CBD20R Capacity: 2000kg Lowered fork height: 82mm Max.

Lifting height: 202mm Fork dimensions: 54/180/1100(11 50/1220)mm Width overall forks: 520/550/650/685mm Battery: 24V210AH Service weight: 710kg Advantages: # The handle is equipped with emergency reverse switch, make the operation more safe.

# Display of electric quantity and display of working time.

# Emergency power off switch.

# Turtle shaped slow running switch.

# Stepless speed change control.

# The balance wheel with spring adjusting structure has good wear resistance and stability.

# AC motor, no carbon brush, has good ramp starting performance.

# The side door and the battery cover can be completely opened up, the battery can be pulled out from the side, easy to change the battery and maintenance.

# Small turning radius, wheel replacement and maintenance is simple and convenient.

# The motor has better dustproof and waterproof effect, which makes the brake and motor more durable, and the reliability is improved.

# Stand on pedal has good shockproof effect, comfortable operation, not easy to fatigue.

# Low voltage protection system to prolong the service life of battery.

# CANbus technology greatly simplifies the line and enhances the reliability of the electric pallet truck.

# Holzer sensor reduces wear and tear of electronic components and increases service life.

# Strong steel cover, easy to open, simple, easy maintenance, and repair.

- - - - SPECIFICATIONS OF STAND-ON TYPE ELECTRIC PALLET TRUCK | Model | | CBD20R | Load capacity | kg | 2000 | Load center | mm | 600 | Load distance | mm | 815/865/935 | Fork height, lowered | mm | 82 | Tyre size, front | mm | 250*70 | Tyre size, rear | mm | 82*126(98) | Additional wheels (dimensions) | mm | 127*57 | Max.

lifting height | mm | 202 | Height of tiller in drive position min.

/max.

| mm | 1150/1430 | Overall length | mm | 1710/1760/1830 | Length to face of forks | mm | 610 | Overall width | mm | 775 | Fork dimensions | mm | 53/180/1100(1150/1220) | Width overall forks | mm | 520/550/650/685 | Aisle width for pallets 1000*1200 crossways | mm | 1910/1960/2030 | Aisle width for pallets 800*1200 lengthways | mm | 2010/2010/2030 | Turning radius | mm | 1550/1600/1670 | Travel speed, laden/unladen | km/h | 7/7.1 | Battery | V/Ah | 24/210 | Service weight | kg | 710 | - - - - Stand-on type platform pallet truck, with small turning radius and super light steering system.

Widely used in large warehouse and big supermarket for medium distance transport.
