Heavy Duty Expanded Steel Gratings - China

Expanded Metal Structural Steel Grating Floor Plates for Stair Tread and Decking Construction.

Available in Oblong Diamond, Reverse Diamond and Hexagonal Holes.

Expanded metal grating is the most practical and economical way to assure strength, safety, and a non-skid flooring surface.

Expanded Steel Grating offers four advantages over welded steel bar gratings: First, Expanded grate is made of one continuous piece of material yielding a greater strength to weight ratio.

Second, Expanded Metal Grating Floor has no welded parts, its flooring surface is naturally skid proof without further processing.

Thirdly, the pattern and openings of Expanded Grating provide a wider range of load capacity flooring to meet exact requirements.

Fourth, Expanded metal grating processed from same material as bar grating costs less for your project.

This metal grating offers ease of fabrication, economy, strength, safety in industrial platform and stair tread decking construction.

Processed from different metal materials including carbon steel, stainless steel and aluminum, Expanded metal grating is ideal for use as walkway and tread plates fencing, plant runways, working platforms, and catwalks.

It can be supplied in light and heavy loading type.

Easily cut into irregular shapes and can be installed quickly by welding or bolting.

General Tech Information: Grating Patterns: Diamond, triangle, scale hole, etc.

Expanded Metal can be processed in different opening shapes, typically as: standard rhombic shape; heavy type Tortoise-shaped; flattened; and some special shapes or designs.

Specification: thickness: 0.5mm-8mm

Hole width: 2.5mm-50mm

Hole length: 4.5mm-100mm

Openness: 0.5mm-8mm Heavy Type Hexagonal Shaped Expanded Metal, Tortoise-shaped Expanded Steel Sheet Mesh, Also Known as Raised Metal Mesh: A kind of reinforced sheet compared with the regular diamond shaped expanded metal products.

Heavy type is ideal for uses in plants, ship-making, mineral sifting, flooring, grating, groove cover, conveying, side passages for conveyors and cranes, fences and decoration of buildings.

Material types available: Stainless steel, galvanized or plain steel.

Company Contact:

• Posted By: Anping PuRuiSe Expanded Metal Factory

• Phone: +86-318-9638287

• Address: No.33, Lingyuan Street, Anping, China, hebei , 053600 , China

• Email:

• Website: https://www.expanded-metal.org

• Business Description: Anping PuRuiSe Expanded Metal Factory is a supplier that is dedicated to producing high quality, precision made metal products.

  PuRuiSe has been in the expanded metal business for about 10 years to offer the best solutions for your needs.

  Many metals can be expanded including aluminium, pre-galvanised mild steel, mild steel hot rolled and cold rolled, stainless steel, zintec, monel, titanium, brass and copper.

  Special precious metals can also be processed to customers requirements including gold, silver and platinum.

  Expanded metal mesh is formed from a single piece of material with no waste in the process.

  The metal material is cut and stretched while still leaving it attached at the knuckle.

  This allows it to retain its shape when cut and cannot separate or fray.

  Often cutting to shape is the only fabrication needed.

  Because of its jointless continuity, it is a highly efficient conductor of electricity, magnetic flux and heat.

  It has excellent corrosion resistance when suitably coated, and the uncut knuckles support weight and withstand stress better than jointed welds or woven materials.

  Expanded mesh can be supplied in a variety of finishes, thickness, raised or flattened.

  Flattened is smoother and does not indent soft materials if this is a consideration but is not as strong as the more robust raised mesh.

  Powder coating in your choice of colour will enhance its aesthetic appearance and add to its corrosion resistance as would plastic coating.

  We can supply in framed panels made to customers specific requirementst.

  PuRuiSe has the most knowledgeable and professional staff working to provide the end user with a valuable and pleasant business experience.
