Casting Steel 6 Inch Flat Gate Valve Reliable Zero Leakage Without Throught Conduit - China
price: check with company for price
Casting Steel WCB Material Flat Slide Plate Gate Valve Without Throught Conduit What is Flat gate valves It is a casted full bore flat valve with flexible wedge, elastomeric closure and external screw suitable even for regulation, manufactured according API standard.
Quick Information: - - - - Size | from 2 to 48 | Pressure | 150 1500LB | Material | WCB, LCB, WC6, WC9, CF8, CF3, CF3M, and CF8M | Design and production standard | API 600, API6D and ASME B16.34 | End to End | API 6D, ASME B16.10 | End Connection | ANSI B16.5, ASME B 16.47, ANSI B 16.25 | Test Standard | API598, API6D | Actuation | can operate with lever, gear box, pneumatic or electric actuator with handwheel for emergencies.
| Medium | The valve is suitable for several media including water, steam, oil, gas, petrol products, nitric acid, acetic acid, etc.
| Working temperature | from -46C or -50C (stainless steel constructions) and -29C (carbon steel constructions) up to 600 | - - - - Product Features 1 - The flat gate valve seat adopts the structure of O-ring seals and pretightening float valve seat, the soft sealing inlays fluoroplastic, it provides the function of double sealings: fluoroplastic to metal and metal to metal.
And at the same time, the fluoroplastic can remove the dirt of the gate disk.
2 - Of the metal to metal sealing, there is a grease injection structure outside the valve, grease injects the sealing part through the seat, in this way achieves the aim of zero leakage.
3 - Through conduit gate valve always coincide with the sealing surface, whether the disc is full open-or full-closed; sealing surface to be protected from scouring by media dilectly, thereby extending the service life.
In full- time, smooth channel for the direct and flow resistance coefficient is extremely small, no pressure drop and head loss.
Company Contact:
- Posted By: TEKO Industry Co., Limited
- Phone: 86-20-84646289
- Address: Xinqiao Industrial Zone, Shiji County, Shiqiao, Panyu Disctrict, Guangzhou, China, Guangzhou , Guangdong , China
- Email:
Published date: April 25, 2018
- Business Description: TEKO Industry Co., Limited, established in 2010, is a rapidly growing industry products manufacturer in China.
Throughout 8 years of development, we have been now becoming the major valve supply in industries of petroleum, chemical plant, power station, mining, metallurgy, waste water treatment, etc.
