Chemical Resistant Mounted Ball Valve Flange Type Electric Actuated Regulating Control - China

Mounted Electric Actuated Regulating Control Flanged Ball Valve For Chemical Resistant Quick info Split Body, stainless steel ASTM A351 - CF8M, flanged ANSI 150 ball valve.

Full port sizes 1/2 to 8 - Blow out proof stem, adjustable stem packing.

PTFE seats, packing and thrust washer.

Standard grounded stem and ball.

100% tested PED 97/23/CE Standard locking device.

Flange ANSI B16.5, length ANSI B16.10 - - Fire Safe approved API 6FA - BS 6755/2 - Antistatic BS 5146 - ISO 7121 - Material List - - - - 1 | BODY | A351 CF8M | 1 | 2 | END CONNECTION | A351 CF8M | 1 | 3 | BALL | AISI 316 (1/2- 11/2) | 1 | STEEL (2 - 8) | 4 | STEM | AISI 316 | 1 | 5 | SCREW | STAINLESS 1/22 | 4 | STEEL 38 | 8 | 6 | NUT | STAINLESS 1/24 | 2 | STEEL 6 - 8 | 1 | 7 | SPRING WASHER | STEEL | 2 | 8 | TRAVEL STOP | AISI 316 | 1 | 9 | PACKING GLAND | AISI 316 | 2 | 10 | STEM SEAT | PTFE | 1 | 11 | HANDLE | AISI 316 | 1 | 12 | STEM SEAT | GRAPHITE | 1 | 13 | O-RING | Viton | 2 | 14 | THRUST WASHER | PTFE | 1 | 15 | SEAT | GRAPHOIL | 1 | 16 | SEAT | PTFE | 1 | 17 | BALL SEATS | PTFE | 2 | 18 | SCREW | STAINLESS STEEL | 2 | 19 | GROWER | AISI 304 | 2 | 20 | SCREW | STAINLESS STEEL | 2 | 21 | BODY HANDLE | CAST IRON | 1 | - - - - *Other material are available upon request Dimensions: - - - - SIZE | U | D | Y | Z | I | L | M | P | R | A | C | W | H | K | E | F | N | B | S | 1/2 | 0.59 | 3.5 | 2.38 | 0.62x4 | 1.83 | 4.25 | M10X4 | 2.72 | 5.2 | 2 | 0.72 | 1.38 | 0.45 | 0.06 | M10 | 0.28 | 1.65 (F04) | M5 | 1.18 | 3/4 | 0.75 | 3.88 | 2.75 | 0.62x4 | 2.09 | 4.62 | M10X4 | 2.8 | 5.2 | 2.07 | 0.72 | 1.69 | 0.51 | 0.06 | M10 | 0.28 | 1.65 (F04) | M5 | 1.18 | 1 | 0.98 | 4.25 | 3.12 | 0.62x4 | 2.34 | 5 | M10X4 | 3.54 | 6.89 | 2.76 | 0.98 | 2 | 0.57 | 0.06 | M12 | 0.31 | 1.97 (F05) | M6 | 1.38 | 11/2 | 1.5 | 5 | 3.88 | 0.62x4 | 3.03 | 6.5 | M12X4 | 5.2 | 9.88 | 4.2 | 1.21 | 2.88 | 0.69 | 0.06 | M16 | 0.39 | 1.97 (F05) | M6 | 1.38 | 2 | 1.97 | 6 | 4.75 | 0.74x4 | 3.39 | 7 | M12X4 | 5.67 | 12.68 | 4.8 | 1.52 | 3.62 | 0.77 | 0.06 | M20 | 0.55 | 2.76 (F07) | M8 | 2.17 | 3 | 2.99 | 7.5 | 6 | 0.74x4 | 3.13 | 8 | M12X8 | 6.77 | 15.04 | 5.96 | 1.68 | 5 | 0.94 | 0.06 | M24 | 0.71 | 4.02 (F10) | M10 | 2.76 | 4 | 3.94 | 9 | 7.5 | 0.74x4 | 4.33 | 9 | M12X8 | 7.32 | 15.04 | 6.5 | 1.68 | 6.19 | 0.94 | 0.06 | M24 | 0.71 | 4.02 (F10) | M10 | 2.76 | 5 | 4.92 | 10 | 8.5 | 0.86x4 | 5.9 | 14 | M12x8 | 8.18 | 15.04 | 7.36 | 1.68 | 7.31 | 0.94 | 0.06 | M24 | 0.71 | 4.02 (F10) | M10 | 2.76 | 6 | 5.91 | 11 | 9.5 | 0.86x4 | 7.13 | 15.5 | M16X8 | 11.34 | 27.56 | 9.65 | 2.68 | 8.5 | 1 | 0.06 | M42 | 1.18 | 4.92 (F12) | M12 | 3.35 | 8 | 7.87 | 13.5 | 11.75 | 0.86x4 | 8.35 | 18 | M20X8 | 13.07 | 27.56 | 11.36 | 2.68 | 10.62 | 1.14 | 0.06 | M42 | 1.18 | 4.92 (F12) | M12 | 3.35 | - - - -
