Enclosed Body Pinch Valve With Abrasion Resisitant Natural Rubber Sleeve For Mining - China

Abrasion Resistant Natural Rubber Sleeve Enclosed Body Pinch Valve For Mining Application Introduction TEKO Valve Control Pinch Valves offer maximum durability with precise control and virtually no maintenance.

A heavy-duty, rugged pinch mechanism positions the sleeve, resulting in accurate flow control.

Our Control Pinch Valves have no packing to maintain or seats to wear, no fugitive emissions and no need for expensive body alloys.

Variable orifice and cone sleeves can be specified to further enhance control performance and match the exact CV level desired.

True feedback positioning is accomplished through the direct linkage of the pneumatic positioner to the valve stem shaft, with no splitting of the positioner output.

TEKO Valve Control Products are available with pneumatic, electropneumatic, or digital positioners to link up to all control systems.

Specifications Size Range: 1" (25mm) to 60" (1500mm) Temperature: -50degF to 250degF Max.

Working Pressure: Up to 300psi (20bar) (consult for higher pressures) Standard Face-to-Face: ASME B-16.10, DIN 3202, ISO 5732 Flange Drilling: ANSI 150#, ANSI 300#, DIN, JIS, AS Actuation: Manual self-lubricating hand wheel, with or without gear reducer Tube Material: NR, PGR, EPDM, NBR, IIR, CR, FPM, CSM (View Chart) In-Line Tube Change: Yes Body Material: Ductile iron (CRN available) or aluminum Valve Advantages & Key Features # Sealed & lubricated closing mechanism # In-line and quick tube change with patented tube folds for durability & self-cleaning # Standard Face-to-Face # Exterior & interior corrosion resistant Fusion Bonded Epoxy Powder coating Available Configurations' CONTROL MODULATING (Sizing available) ISOLATION ON/OFF Applications - - - - Power plant, Coal coking plant | Coal Washery | Wastewater treatment | Steel Corporation | Orel Mine | Chemical Industry | Aluminum Company | Corrosive Liquid | Pharmaceutical industry | Food process | General engineering | Sludge Control | - - - -
