Tobee® 6 4e Ahr Rubber Slurry Pump - China

6/4E-AHR Rubber Lined Slurry Pump is cantilevered, horizontal, centrifugal with double casing slurry pump.

They are designed for the handling of highly abrasive, high-density slurries.

The wet parts of 6x4 slurry pumps are made of natural rubber, which could be replaceable wear-resistant parts.

The discharge side can be oriented to any of the eight different positions.

The shaft seals may adopt packing gland seal, expeller seal and mechanical seal.

Design Features: √ Bearing assembly – A large diameter shaft with short overhang minimizes deflection and contributes to long bearing life.

Only four through bolts are required to hold the cartridge type housing in the frame.

√ Liners – Easily replaceable liners are bolted, not glued, to the casing for positive attachment and ease of maintenance.

Hard metal liners are completely interchangeable with pressure molded rubber.

Elastomer seal rings back all liner joints.

√ Casing – Casing halves of cast or ductile iron with external reinforcing ribs provide high operating pressure capabilities and an extra measure of safety.

√ Impeller – Front and rear shrouds have pump out vanes that reduce recirculation and seal contamination.

Hard metal and molded rubber impellers are completely interchangeable.

Cast in impeller threads require no inserts or nuts.

High efficiency and high head designs are also available.

√ Throatbush – Wear is reduced and maintenance simplified by the use of tapered mating faces to allow positive accurate alignment during assembly and simple removal.

√ One-piece frame – A very robust one-piece frame cradles the cartridge type bearing and shaft assembly.

An external impeller adjustment mechanism is provided below the bearing housing for easy adjustment of impeller clearance.

Company Contact:

• Posted By: HEBEI TOBEE PUMP CO., LIMITED

• Phone: 15633815619

• Address: No. 266, Tianshan St, High-tech Zone, Shijiazhuang City 050000, Hebei , China

• Email:

• Website: https://tobeepump.com/

• Business Description: Hebei Tobee Pump Co.,Limited is a professional manufacturer in designing and manufacturing Centrifugal Slurry Pumps, Pipes & Fittings, Valves etc.

  Our factory is located in the High tech Development Zone, Shijiazhuang City, China.

  We specialized in Horizontal slurry pumps, Vertical slurry pumps, Gravel sand pumps, Dredging pumps, Paper pulp pumps, Molten Salt Pumps, End suction pumps, Double suction pumps, Multistage pumps, Boiler feed water pumps, Self priming pumps, Inline centrifugal pumps, Sea water pumps, Chemical pumps, Irrigation pumps, Fire pumps, API 610 centrifugal oil pumps, Submersible sewage pumps, Slurry Pump spare parts, Pipes & fittings and Valves in domestic and over 80 countries in the world.

  Capacity

  Tobee® Pump has a wealth of experience in the manufacturing and service of pumps and accessories; in fact Tobee® Pump has machinery manufacturing experience of over 45 years having achieved great success with R&D and manufacturing of Pumps for more than 30 years.

  The annual production capacity of pumps in our factory surpasses 10,000 easily.

  Tobee® Pump has a tremendous market share that covers more than 120 cities in China including many provinces and autonomous regions and more than 80 countries.

  Production Capability

  Tobee® Pump has over 80 sophisticated equipment such as CNC, Director reading Spectrometer, CMM (Coordinate Measuring Machine), Rapid typing Machine and etc.

  Based on these facilities, Tobee® Pump has the abilities of material inspection, casting, welding, machining, assembling and the performance test of pump unit.

  The maximum weight of the casting by Tobee® Pump is about 12 tons, the maximum diameter of the casting can be machined by Tobee® pump is over 5 meters and the maximum flow rate of Tobee's Pump product is more than 80,000 cubic meters per hour.

  With an annual production of 1000~120,000 pumps, Presently, Tobee® Pump is the top 10 pump manufacturer with high comprehensive capacity of design and producing.
