Hc220 220ton 2200kn Clamping Force General Purpose Plastic Injection Molding Machine - China

HC220 220Ton 2200KN Clamping Force General Purpose Plastic Injection Molding Machine

General Purpose Plastic Injection Molding Machine

HC Series General Purpose Plastic Injection Machine

Injection moulding machine, high precision injection molding machines with the clamping force range from 60T to 4000T Specifications Unit HC220

INJECTION UNIT A B C

Screw diameter mm 45 50 55

Screw L/D ratio L/D 23.9 21.4 19.3

Theoretical shot volume cm3 342 422 511

Shot weight(PS) g 311 384 465

Injection rate cm3/s 152 187.7 227.1

Injection pressure Mpa 174 141 117

Max.

screw speed rpm 150

CLAMPING UNIT Clamping force kN 2200

Opening stroke mm 465

Distance between tie-bars mm 520 x 520

Max.

mold height mm 530

Min.

mold height mm 200

Ejector stroke mm 145

Ejector force kN 60

OTHERS Drive power kW 18.5

Heating capacity kW 14.2

Machine dimensions m 5.6 x 1.5 x 2

Machine weight t 7.2

Oil tank capacity L 310

CLAMPING PART:

We creates independently the box type high rigidity mold structure for the clamping part; the clamping support guide rail adopts the high rigidity design to reduce the deformation effectively; the toggle structure optimized and designed with computer achieves exceptionally stable and rapid clamping; and the enlarged mold thickness, the gear mold regulation unit and the internally installed mechanical safety lock as well as the 180-degree rotary product blanking bucket, all help achieve your individual demands and make your operation easier!
