Perform Input Pet Bottle Blowing Machinefor 28 38 Mm Diameter Bottles - China

4 cavities can soda plastic water bottle manufacturing machine Technical Sheet PET soft bottle blow moulding machine - - - - | Item | YCQ-2L-4 | Bottle type specification | Cavity | 4 | Theory output (PCS/HR) | 4000-5000 | Max.

volume (L) | 2L | Bottle mouth maximum overall diameter (mm) | 28-38mm | Bottle biggest diameter | 100mm | Bottle maximum height | 330mm | Power specifications | Light tube quantity | 32pcs | Light tube power | 1.25kw | Maximum heating power | 40kw | All electric machine installation | 43kw | Actual consumption | 21.5kw | Air pressure specification | Work pressure | 7-9kg/cM2 | Low-pressure gas consumption | 1600Ltr/min | Blow bottle pressure | 25-35kg/cM2 | Higher -pressure gas consumption | 3000 Ltr/min | Frozen water specification | Work pressure | 5-6 kg/cM2 | Temperature range | 10C | Consumption | 8000kcal/hr | Frozen water flow | 88Ltr/min | Machine specification | Size of the machine | 4.5x1.6x1.9 (m) | - - - - Machine PartsPET soft bottle blow moulding machine - - - - Name | Brand | Original | Blowing cylinder | FESTO | Germany | Mould closing and opening cylinder | FESTO | Germany | valve | FESTO | Germany | PLC | MITSUBISHI | Japan | HMI SCRENN | WINVIEW 506L | Taiwan | Switch | OMRON | Japan | - - - - Machine Features PET soft bottle blow moulding machine # # Automatic perform input and ready bottle output system.

# Machine adopt with the overall structure of super-standard anti-vibration design, high-speed operation state of the machine will shake down to a minimum.

# Machine adopts modular assembly method, greatly decrease the local amendments due to technological improvements when the machine is on processing.

# The structure of machine oven adopt the international most advanced energy-saving technology of infrared radiation heating, temperature control with automatic negative feedback, closed-loop regulation model.

# Automation controlling item adopts international high-end computer system, heating, collecting and measuring perform temperature with simulation input and output module.

# Man-machine interface displays current production situation, available for on line switching, parameter modification and production accounting, with automatic alarm, automatic fault detection and diagnose.

# Storing more than 7 kinds specification for making bottle.

# Adopt latest international air pneumatic.

# In order to save air, we choose high pressure blowing exhaust recovery system, which can save energy by 10-15%.

Note PET soft bottle blow moulding machine # # This machine only need one worker to operate.

# Standard export packing suitable for sea journey .

# Delivery time: 60 days on receipt of the deposit.

# Warranty: one year with one year exchange damage parts .

# The offer is valid in 30days.

# We will install and test the machines and have training lessons abroad, but the round tickets, accommodation, eating, and the allowance of USD 80per day per person will be on customer's side.

# All machine electric Power is about 50KW .
