Cold Rolled Steel Purlin Roll Forming Machine With 15kw Motor Power - China

C60-175 C Purline Galvanized Steel & Cold Rolled Steel Roll Forming Machine Steel Purline Usage Xiamen Bogong C60-175 C Purline Galvanized Steel & Cold Rolled Steel Roll Forming Machine combines with steel uncoiler, seven rollers straightening device pre-punch hole section, roll forming machine and post cutting device, whole producing line controlled by PLC control system.

C Purline Galvanized Steel & Cold Rolled Steel Roll Forming Machine also can be called Interchangeable C purline Forming Machine, automatic purlin size change roll forming machine.

Compare to manually type change purline roll forming machine, it can save human cost and time cost much.

C60-175 C Purline Galvanized Steel & Cold Rolled Steel Roll Forming Machine is the popular sizes for Philiphines market.

All the sizes you need to produce between 60mm to 175mm can be set on PLC control screen and the system will produce corresponding size under the program setting task.

Advantage Of Bogong Machinery C Purline Roll Forming Machines 1 - Xiamen Bogong brand C60-175 C Purline Galvanized Steel & Cold Rolled Steel Roll Forming Machine is suitable for galvanized steel sheet, hot dip steel coil or sus steel frame.

2 - PLC control system controll the producing task, purlin size will be set on screen, the type change operation is easy for study, good for maintenance.

3 - 24 hours accept customized roll forming machines, we can make and design kinds of roll forming machine according to customer's request.

Forming Ribs on bottom place: Technical Parameter - - - - Parameters | Specification | Voltage | 380V/50HZ/3PH | Driving Motor | 15KW | Hydraulic Cuting Motor | 5.5KW | Motor For Width Adjust | 0.75KW*3 | Forming Steps | 18 | Working Speed | 15-20m/min | Thickness for Steel | 1.0-2.0mm (Material: PPGI, GI Steel G550) | Shaft Diameter | 75mm | Shaft Material | High grade 45# forged steel | Roller Material | Gr15 steel with polished and heat treatment | PLC Cabinet | Schneider | Encoder | Omron | Sprocket Wheel | 45 steel high-frequencies quench | Cut-off System | Post punching post cutting | Cutting Blade Material | Cr12 steel | Machine Frame Material | Fine welded structural steel; | Roofing Material | PPGI, GI steel G330-550 | Painted Color | Blue+Gray White Or Customization | Overall Size | 9200*1400*1800mm | Weight | 8500KGS | - - - - Purlin Design Drawings Material Straigtening Rollers & Roll Former Whole C purlin Roll Forming Machines
