Corrugated Roof Custom Roll Forming Machine Dual Layer High Performance - China

Customized Metal Corrugated Roof Sheet Double Layer Roll Forming Machine Description As a specialized Customized Metal Corrugated Roof Sheet Double Layer Roll Forming Machine manufacturer and supplier in China, Xiamen Bogong Machinery brandCustomized Metal Corrugated Roof Sheet Double Layer Roll Forming Machine is suitable for trapezidal roofing design, corrugated roof design, railway carriage roof.

With large and customize width of raw material, the material thickness is also changeable, This is only the one model of our series roll forming machines, except this, we Xiamen Bogong Machineryalso provides steel house frame roll forming machine, guard rail forming machine, step tile roof roll forming machine, decking floor roll forming machine, roller shutter door roll former, door frame roller forming line and other special design from buyer.

Technical Parameter - - - - Machine Component | Specification | 5Tons Manual Deocoiler | Coil Inner-diameter=51030mm.

Coil Outer-diameter Max.

1300mm | Taper wedge expanding system | Load Capacity: Max.

5 Tons; Coil Width Max.

1250mm | Dual Layer Cold Rolling Machine | Gear/Sprocket driving; 16 stations forming | Rollers manufactured from 45# steel, CNC lathes, hard Chrome Coated, fine polished.

| Shafts Diameter=75mm, Precision Machined, fine Polished | Main motor =7.5KW, Frequency speed control | Max Line speed of roll Former: Approx.

10-15m/min | Hydraulic Cutting Device | Stop to cut, Post cut, slug cut | Cutting tool material: Cr12, Heat treatment | Hydraulic unit, Pump motor =3KW | PLC Control System | Control the quantity & cutting length automatically | Combined with: PLC (Siemens), Touch Screen (Siemens), Encoder (Omron), etc | Cut-to-length tolerance2mm | 24V Control voltage | Portable controller with forward/backward/emergenc y stop buttons | Product Rack | Un-powered, 3 units | - - - - Machine Details Whole Customized Metal Corrugated Roof Sheet Double Layer Roll Forming Machine apperance as below:
