Galvanized Steel C U Channel Roll Forming Machine Heavy Duty Big Size - China
price: check with company for price
Galvanized Steel Heavy Duty Big Size C / U Purlin Roll Forming Machine Description This Galvanized Steel Heavy Duty Big Size C / U Purlin Roll Forming Machine isfor our customer in India, raw material thickness is about 4.5mm, we design the rolling shafts diameter as 110mm, and uncoiler width clamper for holding the steel strip.
The U400 purlin is used for big cover width steel structure, consider for safety, the final user customized this Galvanized Steel Heavy Duty Big Size C / U Purlin Roll Forming Machine.
As the popular steel structure material, C purlin is a traditional building materials in steel construction area, the products are widely used as steel roof and wall support frame of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc.
It has many advantages, such as easy installation, short building period, beauty, light weight but high strength.
Welcome to come customized yourself roll forming machines! Technical Parameter - - - - Parameters | Specification | Voltage | 380V/50HZ/3PH | Driving Motor | 30KW | Hydraulic Cuting Motor | 15KW | Working Speed | 10-15m/min | Steel Thickness | 4.0-5.0mm (Material: PPGI, GI Steel G550) | Shaft Diameter | 110mm | Shaft Material | High grade 45# forged steel | Roller Material | Gr15 steel with polished and heat treatment | PLC Cabinet | Schneider | Encoder | Omron | Sprocket Wheel | 45 steel high-frequencies quench | Cut-off System | Post punching post cutting | Cutting Blade Material | Cr12 steel | Machine Frame Material | Fine welded structural steel; | Roofing Material | PPGI, GI steel G330-550 | Painted Color | Blue+Gray White Or Customization | Overall Size | 9500*1400*1800mm | Weight | 22000KGS | - - - - Steel Coil on Uncoiler
Company Contact:
- Posted By: Xiamen Bogong I & E Co., Ltd.
- Phone: 86-592-6382566
- Address: Area 5, No. 788 Jimei North Road, Jimei District, Xiamen, China, Xiamen , fujian , China
- Email:
Published date: April 25, 2018
- Business Description: With good faith in roll forming machines industrial, Xiamen Bogong Automatic Technology Co.
Ltd has been on effort for kinds of roll forming machines more than 10 years.
During this period, except ourselve roll forming machines, many oversea customers need other assistant help such steel coil.
