Guide Rails Shutter Door Roll Forming Machine For Light Steel Construction - China

Silencer Cotton Shutter Door Guider Guide Rails Roll Forming Machine Steel Rollers Main Features Metal Rollers Silencer Shutter Door Guide Rails Roll Forming Machine YX55-42 choose roll forming method, forming part ofshutter door guider shape at first, after roll forming machine's 9th station, silencer cotton will be installedinside roller shutter door plate automatically.

With silencer cotton, we can ensure the noise is much more less than before when we cloose or open the roller shutter door.

Introduction Of Silencer Cotton Shutter Door Guider Guide Rails Roll Forming Machine Steel Rollers 1 - Our roller shutter door guiderroll forming machine is widely used in light steel construction area, shop, garage and steel construction factory etc.

2 - Line speed of door guider roll forming machine is 0~15m/min.

3 - This YX55-42 steel metal trapezoidal roof panel roll forming machine production line consists of feeding unit, uncoiler, feeding guide, roll forming machine, cutter, automatic stacker, hydraulic system and electric control system.

TechnicalProcess Uncoiler---Feeding---Leve lingRoll Forming---Cutting---Produ cts Collecting Silencer Cotton Shutter Door Guider Guide Rails Roll Forming Machine Steel RollersTechnical Prameter - - - - Voltage | 380V/50HZ/3PH | Driving Motor | 4KW | Hydraulic Motor | 3KW | Forming Steps | 16 | Working Speed | 0-15m/min | Roofing Height | 55mm | Effective Width | 42mm | Material Width | 174mm | Thickness for Steel | 0.6-1.0mm | Tolerance for Cutting | 2mm | Tolerance for Roof Width | 1mm | Shaft Diameter | 65mm | Shaft Material | High grade 45# forged steel | Roller Material | Gr15 steel with polished and heat treatment, | 45# forged steel coated by chrome | Sprocket Wheel | 45 steel high-frequencies quench | Cut-off System | Hydraulic cutting device | Cutting Blade Material | Cr12 steel | Machine Frame Material | Fine welded structural steel; | Roofing Material | PPGI, GI steel | Painted Color | Blue+Gray White Or Customization | Overall Size | 8500*750*1350mm | Weight4 | 4000KGS | - - - - Silencer Cotton Shutter Door Guider Guide Rails Roll Forming Machine Steel Rollers Components Un coiler Straightening and Feeding Equipment roll forming machine Cut-off with cutting blade Run out table Silencer Cotton Shutter Door Guider Guide Rails Roll Forming Machine Steel RollersDesign drawing and sample See below design, YX55-42 silencer cottonRoller Shutter Door Guider Roll Forming Machinedesign and sample Roll Forming Machine Bogong Advantage 1 - Factory team work, rich experience in design, manufacture and export for roll forming machines.

2 - Kinds of ustomized roll forming machines according to your requests.

3 - Good and strong quality steel materials, famous electric part and system for whole roll forming machines line.

4 - Groups of professional engineers, designers and oversea sales for roll forming machines.

Company Contact:

• Posted By: Xiamen Bogong I & E Co., Ltd.

• Phone: 86-592-6382566

• Address: Area 5, No. 788 Jimei North Road, Jimei District, Xiamen, China, Xiamen , fujian , China

• Email:

• Website: https://www.customrollformingmachine.com

• Business Description: With good faith in roll forming machines industrial, Xiamen Bogong Automatic Technology Co.

  Ltd has been on effort for kinds of roll forming machines more than 10 years.

  During this period, except ourselve roll forming machines, many oversea customers need other assistant help such steel coil.
