Pre Painted Galvanized Steel Corrugation Roof Sheet Roll Forming Machine - China
price: check with company for price
Pre-painted / Galvanized Steel Corruation Roof Sheet Roll Forming Machine Introduction Of Corrugation RoofRoll Forming Machine Corrugation roof sheet roll forming machine is the machine for roll forming steel or aluminum coil into waves shape, it is suitable for pre-painted coil, galvanized coil and aluminum coil.
This whole roll forming line consists of feeding unit, uncoiler, feeding guide, roll forming machine, cutter, automatic stacker, hydraulic system and electric control system.
When steel coil thickness is smaller than 0.3mm, due to steel coilperformance, the corrugated roof is hard forroll forming into correct dimension, ourPre-painted / Galvanized Steel / Aluminum Corrugation Roof Sheet Roll Forming Machineis well solving this problem, our high level engineerteam and technician team, we canmanufacture the steel coil thickness under 0.2mm, welcome come to inspect! Design Drawing Technical Parameter - - - - Machine Component | Specification | 5Tons Manual Deocoiler | Coil Inner-diameter=51030mm.
Coil Outer-diameter Max.
1300mm | Taper wedge expanding system | Load Capacity: Max.
5 Tons; Coil Width Max.
1250mm | Corrugation roof sheet roll forming machine | Gear/Sprocket driving; 18 stations roll forming | Rollers manufactured from 45# steel, CNC lathes, hard Chrome Coated, fine polished.
| Shafts Diameter=75mm, Precision Machined, fine Polished | Main motor =7.5KW, Frequency speed control | Max Line speed of roll Former: Approx.
10-15m/min | Hydraulic Cutting Device | Stop to cut, Post cut | Cutting tool material: Cr12, Heat treatment | Hydraulic unit, Pump motor =3KW | PLC Control System | Control the quantity & cutting length automatically | Combined with: PLC (Delta), Touch Screen (Delta), Encoder (Omron), etc | Cut-to-length tolerance2mm | 24V Control voltage | Controller with forward/backward/emergenc y stop buttons | Product Rack | Un-powered, 3 units | - - - -
Company Contact:
- Posted By: Xiamen Bogong I & E Co., Ltd.
- Phone: 86-592-6382566
- Address: Area 5, No. 788 Jimei North Road, Jimei District, Xiamen, China, Xiamen , fujian , China
- Email:
Published date: April 25, 2018
- Business Description: With good faith in roll forming machines industrial, Xiamen Bogong Automatic Technology Co.
Ltd has been on effort for kinds of roll forming machines more than 10 years.
During this period, except ourselve roll forming machines, many oversea customers need other assistant help such steel coil.
