Steel Roof Sheet Custom Roll Forming Machine Double Layer 5 5kw Driving Motor - China

price: check with company for price

Steel Roof Sheet Double Layer Roll Forming Machine Duel Level Roof Roll Forming Machine Double Layer Roll Forming Machine Description Our Bogong Machinery's steel roof sheet double layer roll forming machine is designed for two roof sheet designs, one is YX28-234-954 steel roof, another is YX22-143-1001 roof.

This roll forming machine has been manufactured for our Philiphines customer, the purpose is for saving factory place and manufacturing cost, two layers can not be run on the same, when we need to produce upper layer roof roll forming design, the low layer should be stopped and lock.

Whole roll forming lines can work smoothly like only one layer roof sheet roll forming machine.

See below two roof sheet design for this double layer steel sheet roll forming machine for reference: Technical Parameter - - - -

Machine Component | Specification | 5Ton*1250mm Hydraulic un-coiler | Hydraulic system to expand coil inner holePump motor: 3KW | Frequency Inverter to regulate turn speedMotor: 4KW | Coil Inner-diameter=51030mm.

Coil Outer-diameter Max.

1300mm | Taper wedge expanding system | Load Capacity: Max.

5 Tons; Coil Width Max.

1250mm | Automatic stopping device with limited switch as assistance to control stop/start rotation | Seperated electric controller, out of control system of the complete line | Entry roller & Dual Pre-shearing device | Manual pre-shearing, to cut off the first and end of piece sheet only, Working thickness up to 0.8mm | Dual Layer Cold Rolling Mills | Gear/Sprocket driving; Dual Levelling | Upper Level for YX28-234-954, 16 step to form | Lower Level for YX22-143-1001roof profile, 17-step to form | Rollers manufactured from 45# steel, CNC lathes, hard Chrome Coated, fine polished.

| Shafts Diameter=75mm, Precision Machined, fine Polished | Main motor =5.5KW, Frequency speed control | The two levels cant be run at the same time | Manual Clutch to switch the driven system | Max Line speed of roll Former: Approx.

10-20m/min | Hydraulic Cutting Device | Stop to cut, Post cut, no blanking cut | Two pairs of cutting blade, each profile one blade | Cutting tool material: Cr12, Heat treatment | Hydraulic unit, Pump motor =3KW | PLC Control System | Control the quantity & cutting length automatically | Combined with: PLC (Siemens), Touch Screen (Siemens), Encoder (Omron), etc | Cut-to-length tolerance2mm | 24V Control voltage | Portable controller with forward/backward/emergenc y stop buttons | Product Rack | Un-powered, 3 units | - - - - Roll Forming Machine PLC Control


Company Contact:


  • Phone: 86-592-6382566

  • Address: Area 5, No. 788 Jimei North Road, Jimei District, Xiamen, China, Xiamen , fujian , China

  • Email: Email


Published date: April 25, 2018

  • Business Description: With good faith in roll forming machines industrial, Xiamen Bogong Automatic Technology Co.

    Ltd has been on effort for kinds of roll forming machines more than 10 years.

    During this period, except ourselve roll forming machines, many oversea customers need other assistant help such steel coil.
