380v 50hz Copeland Scroll Outdoor Condensing Unit 6hp For Medicine Cold Room - China

6HP Scroll Series Air Cooled Condensing Unit For Medicine Cold Room 1 .

Anti - corrosion fin increase the life span of the coil .

2 .

Seamless inner groove copper tube is used to increase the heat exchange rate by reducing the space between the fin and copper tube .

3 .

Highest quality compressor in the world .

4 .

Head pressure control stabilized the freezing of liquid line, minimizes formation of flash gas to increase efficiency of system and prevents compressor damage by controlling high pressures .

5 .

Experienced engineers have designed the system for maximum efficiency .

6 .

Fan blades, specifically matched with motors and coil for maximum air movement and cooling 7 .

Fan control system type available .

8 .

Control box is designed for easy installation .

9 .

Low pressure control is adjustable .

10 .

Wiring, easily accessible compressor comes with a wiring harness that is manufactured with connections that will not come loose with vibration .

11 .

Control box and service valves are located outside for easy service .

12 .

Base, heavy duty steel .

13 .

Cabinet pre - painted with galvanized body, protects against corrosion 14 .

All products carry CE approvals .

15 .

All replacement parts are universal .

16 .

All units had been vacuumized and charged refrigerant R404a .

17 .

All split units have complete accessories, Such as : 1, 2 pcs of foamer 2, 6 meters of drain pipe ( It will add more 4 meters of insulation pipe if freezer unit ), 4 meters of drain heater, 3 pcs of drain elbow & 3 pcs of dirct connection, 1 bottle of PVC pipe gluewater .

200mm long soft drain pipe & 2 pcs of pipe clamp .

3, 1 pc of small control box, 5 meters of control cable ( to connect to control box with unit ) .

Air - Cooled Refrigeration Unit Technical parameters : 1 .

Condenser Details : Qty Of Fan ( piece ) : 2 Air Volume ( m3 / h ) : 2 * 3200 Power of Fan ( W ) : 2 * 60 2 .

Refrigerant Capacity Of Compressor : a.

Evaporating Temperature - 5 Cooling Capacity : 10100 W Power : 5920 W b .

Evaporating Temperature - 12 Cooling Capacity : 8060 W Power : 5570 W 3 .

Coupling Tube Coupling : 1 / 2 Suction Coupling : 3 / 4 4 .

Overall Dimensions : Length ( L ) : 980mm Width ( B ) : 410mm Height ( H ) : 1330mm 5 .

Mounting Dimensions : Length ( D ) : 625mm Width ( E ) : 380mm Standard configuration of units : compressor, condenser, liqid receiver, pressure controller, pressure gauge, filter, solenoid valve and wiring box, etc .

Note : 1 .

Cooling capacity in the form iscalculated when the ambiernt temperature is 32 - 2 .

Configuration can be added according to customers' requirements .

3 .

When the compressor using refrigerant R22, and evaporating temperature lower than - 15 cylinder head fan must be installed .

When the evaporating temperature below - 25 the compressor hydrojet system also must be installed .

4 .

When the compressor using refrigerant R404a, and evaporating temperature lower than - 20 cylinder head fan must be installed .
