6hp Copeland Scroll Condensing Units Air Cooled For Glass Door Cold Storage - China

Scroll Compressor Refrigerating Condensing Unit For Glass Door Cold Storage Product Features : Copeland Scroll compressor offers versatility and superior performance, as well as its high efficiency .

Plus, Hermetic scroll type copeland compressor reduces the sound level and raises the adaptation to the environment .

At the same time, the fans space was increased, which can work under higher powder content .

Units are matched with complete parts .

Customers could just connect the tubes and wires before usage .

Air - Cooled Refrigeration Condensing UnitTechnical parameters : 1 .

Condenser Details : - - - - Qty Of Fan ( piece ) | Air Volume (m3 / h ) | Power of Fan (W ) | 2 | 2 * 3000 | 2 * 120 | - - - - 2 .

Refrigerant Capacity Of Compressor : a .

Evaporating Temperature5 - - - - Cooling Capacity | 10950 W | Power | 5640 W | - - - - b.

Evaporating Temperature15 - - - - Cooling Capacity | 7780 W | Power | 5250 W | - - - - c .

Evaporating Temperature- 20 - - - - Cooling Capacity | 6060 W | Power | 5210 W | - - - - 3 .

Coupling - - - - Tube Coupling | 1 / 2 | SuctionCoupling | 7 / 8 | - - - - 4 .

Overall Dimensions : - - - - Length ( L ) | 1010mm | Width ( B ) | 710mm | Height ( H ) | 670mm | - - - - Standard configuration of units : compressor, condenser, liquid receiver, pressure controller, pressure gauge, filter, solenoid valve and wiring box, etc .

Note: 1 .

Cooling capacity in the form is calculated when the ambient temperature is 32 .

2 .

Configuration can be added according to customers requirements .
