Customized Semi Hermetic Condensing Unit Cold Room Freezer Units For Hotel - China

Customized Semi - Hermetic Air Cooled Condensing Unit For Hotel Cold Room Semi - Hermetic Air - Cooled Refrigeration Unit Technical parameters : 1 .

Condenser Details : - - - - Qty Of Fan ( piece ) | Air Volume ( m3 / h ) | Power of Fan ( W ) | 1 | 1 * 800 | 1 * 120 | - - - - 2 .

Refrigerant Capacity Of Compressor : a.

Evaporating Temperature25 - - - - Cooling Capacity | 2830 W | Power | 2070 W | - - - - b .

Evaporating Temperature - 35 - - - - Cooling Capacity | 1650 W | Power | 1490 W | - - - - 3 .

Coupling - - - - Tube Coupling | 3 / 8 | Suction Coupling | 7 / 8 | - - - - 4 .

Overall Dimensions : - - - - Length ( L ) | 600mm | Width ( B ) | 700mm | Height ( H ) | 520mm | - - - - 5 .

Mounting Dimensions : - - - - Length ( D ) | 550mm | Width ( E ) | 420mm | - - - - Standard configuration of units : compressor, condenser, liqid receiver, pressure controller, pressure gauge, filter, solenoid valve and wiring box, etc .

Note : 1 .

Cooling capacity in the form iscalculated when the ambiernt temperature is 32 - 2 .

Configuration can be added according to customers' requirements .

3 .

When the compressor using refrigerant R22, and evaporating temperature lower than - 15 cylinder head fan must be installed .

When the evaporating temperature below - 25 the compressor hydrojet system also must be installed .

4 .

When the compressor using refrigerant R404a, and evaporating temperature lower than - 20 cylinder head fan must be installed .
