Hydroman® Electric Motor Small Submersible Mine Slurry Mud Pump With Side Agitators - China

Hydroman® Electric Motor Small Submersible Mine Slurry Mud Pump with Side Agitators is a continuous flow type of pump that works submerged and is capable of handling abrasive slurries.

It has an inlet at the suction of the pump that increases the speed of the slurry through the vanes of a rotating impeller, producing centrifugal force which sends the slurry through the casing to the discharge.

The casing is a horn-shaped element that transfers speed into pressure.

The Submersible Slurry pump performance is defined by the design of the casing and the impeller.

The efficiency is related to the number and design of vanes in the impeller.

Handling slurries, efficiencies are usually compromised by clearances and the need to build abrasion resistant heavy duty components, taking in consideration materials, thickness, etc.

TSQ Submersible Slurry pump is electrically driven.

The motor shaft carries the impeller.

Design Features:

▪ Hydroman Electric Motors are all Class H insulated and have a minimum 1.25 service factor.

▪Hydroman Submersible Slurry Pumps are equipped with a unique lip seal system to prevent material from penetrating the seal.

▪ High quality abrasion resistance materials ensure long life of all components.

▪ Temperature sensor, embedded in the electric motor, and Moisture sensor, in the oil chamber, are available options to protect the pump in the most demanding application.
