Hydroman® Electric Submersible Dredging Pump With Side Agitators For Dewatering Solution - China

Hydroman® Electric Submersible Dredging Pump with Side Agitators for Dewatering Solution is a submersible three-phase portable slurry pump, the submersible sand solids pump is equipped with a high-chromium alloy agitator which helps to inhale the sediment smoothly together with working in conjunction to make this the optimal dredging system for handling compact muds or other highly viscous materials containing a high percentage of solids, all without the risk of damaging sensitive liners for achieving high-concentration delivery without auxiliary devices.

Electric submersible dredge pump made of hyperchrome wear-resistant material has a very high efficiency and durability compared with ordinary cast iron materials.

The water jetting ring for submersible slurry pump contains high-pressure spray nozzles can be adjustted by a small auxiliary pump that are effectively used to agitate densely packed or consolidated materials to make them easier to feed the pump with a more consistent material flow rate.

So submersible sand pump, water jetting ring, agitator work in conjunction to be powerful pumping system that can easily pump thick mud up thousands of feet through discharge pipelines without the need for additional booster pumps.

The structural characteristics submersible electric slurry sand pump are described as follows:

▪ Hydroman submersible slurry pump / sand pump / sewage sludge pump / mud pump / solids pump can be deployed via an excavator boom, cable hung from a crane, or floating A-frame with little to no modification.

▪ Submersible Sludge Mud Pump reserved lube oil inspection ports that is a wideangle port outside the pump to ensures easy inspection of shaft seal oil levels as well as providing easy access for oil replacement.

▪ Temperature sensor, embedded in the electric motor, and Moisture sensor, in the oil chamber, are available options to protect the pump in the most demanding application for a long time.

▪ The unique sealing device can effectively balance the pressure inside and outside the oil chamber, so that the pressure at both ends of the mechanical seal is balanced, ensuring the reliable operation of the mechanical seal to the greatest extent, and greatly extending its service life.

▪ Electric motors are all Class H insulated and have a minimum 1.25 service factor.

▪ The motor is submerged in the water, and there is no need to construct complicated ground protection and fixing devices, and the management is easier.

▪ Submersible dredging sand pump is directoly submerged in the water not limited by the suction range, the slag suction efficiency is high, and the silt dredging is more thorough.

Hydroman® Submersible Dredging, Slurries and Solids Pump with Water Jet Ring Applications:

Removal of silt build up at marinas, harbors, dock loading facilities, etc.

/ Waste sludge handling / Tank clean out / Waste collection ponds / Dredging deep deposits / Sands mining / Barge unloading / Waste collection pit / Ash sumps / Dredging waste ponds / Clean up sumps / Gold tailings reclamation / Settling and collection ponds / Underground slimes collection ponds / Conveyor tunnel sumps / Coal tailings relocation / Crusher sumps
