Valveless Hammer Bit Ql80 Water Well Drilling Dth - China

Key Specifications/Special Features:

Valveless hammer bit QL80, water well drilling DTH bit Description:

Product name: DTH drill bit QL80N

Processing type: Forging

Material: YK05 + alloy steel

Bit size: 8"

Shank length (excluding valve): 332mm

Bit diameter range: 194~305mm

Color: Yellow/gold/red and others as your requirement.

Apply to: Surface and underground mining, tunneling, geological exploration, quarries, dam construction, construction, water well Bit head design and selection:

1 - Flat front spherical Applications: for drilling in hard and abrasive rock

2 - Flat front spherical + ballistic Applications: for drilling in medium-hard to hard and moderately abrasive rock

3 - Convex front spherical + ballistic Applications: for drilling in medium-hard and moderately abrasive rock

4 - Convex front ballistic Applications: for drilling at high-penetration rates in non-abrasive rock

5 - Concave front spherical Applications: for drilling in medium-hard, minimum hole deviation control Italian Cieffe atmosphere-controllable sealed quench furnace for heat treatment modern CNC machines for accurate finishing which contribute to the excellent performance of all our drilling tools

WOOKE'S DTH Button Bits Size Assortment

Bit Size DTH bits diameter Shank type of DTH Bits

2", 2.5" 76mm~80mm CWG76, BR2, DHD2.5N

3", 3.5" 90mm~105mm COP34(DHD3.5, IR3.5), Mission30, BR3, Mach33, Wooke30

4" 105mm~130mm COP44 (DHD340, IR4), DHD340N, Mission40, QL40, SD4, BR4, Mach44, TD40, Wooke40

5" 133mm~152mm COP54 (DHD350, DHD350R), DHD350N, Mission50, SD5, QL50, QL50N, Wooke50

6" 152mm~254mm COP64(DHD360, IR6), DHD360N, Mission60, SD6, QL60, QL60N, Wooke60

8" 194mm~305mm COP84, DHD380, DHD380N, Mission80, SD8, QL80, QL80N, Wooke 80

10" 240mm~311mm Wooke 100

12" 305mm~445mm Wooke 120

*Face design and button type and dia, all can be customized, please contact our sales for more information.

Company Contact:

• Posted By: Wooke Rock Drill Equipment Co.,Ltd.

• Phone: +86-717-6262131

• Address: Wujiagang Industrial Park, Yichang , Hubei , China

• Email:

• Website: http://www.wooke-intl.com/

• Business Description: Wooke is one of the leading and ISO9001: 2008 certified manufacturers of rock drill equipment established in 1995.

  Also we are one of the three biggest air pressure DTH drilling tools factories in China, as well as one of the best high-air-pressure DTH drilling tools manufacturers in China.

  We mainly produce and supply customers a variety of :

  --- High, medium and low air pressure DTH hammer and bits.

  --- API standard DTH drill pipes.

  --- Eccentric and symmetric casing systems.

  --- Hydraulic top hammers including tapered button bits, coupling sleeves and shank adapters.

  --- RC hammers and bits

  --- Kinds of adapters.

  All of our products have the features :

  * Capable of drilling in almost all ground conditions.

  * Designed for maximum performance

  * Made of quality steel with tungsten carbide buttons.

  * Percision machined and heat treated to the required hardness.

  When you purchase our drill tools, we are sure that you will be overwhelmingly satisfied with the performance and durability.

  Welcome to contact us via wooke.

  cyndee@gmail.

  com / WhatsApp: +8613277255863
