Geophone Zf 10 Part No 1z6101 - China

price: 15.00 Dollar US$

Geophone Zf 10 Part No 1z6101

Products Photos Catalog Geophone 1z6101 Photos Catalog

Harmonic distortion≤0.075%

Typical spurious frequency≥240Hz

ZF-10 is compatibile to SG-10

Natural frequency 10±2.5%

Coil resistance 350±2.5%

Open circuit sensitivity(v/m/s) 22.8±2.5%

Open circuit damping 0.68±5%

Distortion (%)≤0.075

Typical spurious frequency(Hz) ≥240

Moiving mass(g) 8.4

Max.

coil excursion P.

P(mm) 1.78

Allowable tilt(°) 15

Length(mm) 30.15

Diameter(mm)27.4

Weight(g) 78

Positive terminal

Free termial closes to the “+”sign

Storage temperature(°C) -40to+90

Operating temperature(°C)-40to90

Limited warrantly period ：3years

Note：Except where othervise noted all elctromechanical specification are valid at 25(°C)and from 0to 10 degree tilt.

Warrantly excludes damage caused by high-voltage or physical damage to the element case


Company Contact:


  • Phone: 86-10-87576701

  • Address: Rm1205, 3rd Building, Soubao International Centre,No.16 Nansanhuanxi Rd, Fengtai District ,Beijing, , beijing , china , China

  • Email: Email


Published date: August 11, 2016 - Modified date: August 12, 2016

  • Business Description: Capacity：

    Based on dust free geophone element workshop and geophone string assembly line, ZF can manufacture 2.5 million geophone elements and 0.1 million typical geophone strings per year, while more that 1.09 million seismic connectors and other spare parts are manufactured by ZF every year.

    ZF cable department mainly produces geophone cables, seismic cables and custom cables, with a capacity up to 37, 000 KM of typical digital cables and leader wires per year.
