Hz 200yy Hydraulic Portable Bore Well Drilling Rig - China
price: 2000.00 Dollar US$
1 - The applications of HZ-200YY drilling rig
HZ-200YY drilling rig is mainly used for water well, field irrigation well, engineering water well, precipitation well and so on;geological general investigation and exploration, road and tall building foundation exploration, holes in concrete structure, river levees.
2 - The features of HZ-200YY drilling rig
The highest speed can reach 1045r/min with 5 gears, improved drill efficiency
Adopted 53 x 59 drilling rod, high rigidity and strong delivery torque
Equipped with national patent technology---taper clutch, make the machine easy to operate and free maintenance.
Use large module planetary gear and add supporting frame, highly increased hoisting and braking ability of the winch.
3 - The specifications of HZ-200YY drilling rig
Maximum open hole diameter 300mm
End hole diameter 75mm
Drilling pipe diameter 50mm/60mm
Drilling angle 90°
Drilling rig weight (without power) 975kg
triangular belt B950 x 4; B1700 x 3
Active move distance 300mm
Power diesel engine 20hp electric motor 15kw
Spindle
Spindle rotating speed 64/128/287/557r/min
Spindle stroke 450mm
Windlass
Maximum lifting power of a single rope 2400kg
Lifting speed of a single rope 0.41/0.82/1.64m/s
Wire rope diameter 13mm
Drum capability 35m
Band-type break diameter 260mm
Band-type break belt width 70mm
Mud pump
Model horizontal single-urn twin-action
Displacement diesel engine 170l/min electric motor 150l/min
Maximum pressure 3mpa
Work pressure 1.5mpa
Water inlet pipe diameter 40mm
Water outlet pipe diameter 30mm
Triangular belt B1728mm
