Khyd125 7 5kw Coal Mine Electric Motor Hard Rock Drilling Rig - China

Key words: portable rock drilling rig, hard rock drilling rig, core drilling rig for hard rock, mine rock drilling rig, electric drilling rig

1 - The brief introductions of KHYD125 rock drilling machine

Drilling rigs can be fitted with drilling rigs, and can be drilled horizontally or inclined upward or upward.

In order to prolong the service life of the drill bit and improve the working conditions of the operator, wet drilled water can be used to discharge the powder and screw blade drills can also be used for dry draining.

In drilling operations, we only need to operate the hand wheel, and we can advance and return quickly.

2 - The specifications of KHYD125 rock drilling machine

Model Unit KHYD125

Rated output power of electric motor kw 7.5

Rated voltage of electric motor v 380/660

Rated frequency of electric motor hz 50

Rated current of electric motor a 15.4

Motor rotating speed r/min 1440

Motor phase number three phase communication

Rated working mode continuity

Drilling speed mm/min 280

Speed of return m/min Borehole diameter mm 42-80(rock stratum)

Harness range protodikonov`s scale of hardness f<10

Maximum drilling depth m 25(rock stratum)

Weight of drilling rig (excluding runways, drill pipes, drills) kg 125

Dimension(length *width *height) mm 950*460*430
