200m Full Hydraulic Jet Grouting Borehole Drilling Rig Coal Mine Tunnel Drill Machine - China

price: 100.00 Dollar US$

1 - Brief introductions of ZLJ650 grouting reinforcement drilling rig

ZLJ-650 grouting reinforcement drilling rig is mainly used for drilling holes with different angles in underground mine, tunnel, subway and slope support.

This drilling rig adopts mechanical drive, hydraulic feed with small size, light weight, The drilling rig is reliable and convenient to operate.

2 - Specifications of ZLJ650 grouting reinforcement drilling rig

Drilling hole diameter 50-113mm

Hole depth 200m

Drilling pipe diameter 42mm

Open hole diameter 50-113mm

End hole diameter 56-113mm

Vertical rated speed 340 192 112 r/min

Vertical shaft torque rating 130/ 230/ 400 n.

m

Main shaft angle 0-360

Spindle stroke 400mm

System pressure rated 8mpa

Feeding force 9kn

Elevating power 12kn

Winch lifting capacity 7.35kn

Drum Capacity 26.8m

Wire rope diameter 8.85mm


Company Contact:


  • Phone: 8619806265526

  • Address: Wu taizha road, guanhe street,, Jining , Shandong , China

  • Email: Email


Published date: September 24, 2019

  • Business Description: Group for a long time in line with the giants of masters of "the spirit of craftsman, creates quality" concept of enterprise development, challenge pragmatic development, now has developed into a collection of research and development design, manufacture and market sales in the integration of many company joint operation of collectivization, giant group members have jining machinery research institute, shandong machinery manufacturing co., LTD., the giants of the giants and huge machinery co., LTD., shandong province, China, etc.
