China Qz 2cs Gasoline Core Drilling Rig Manufacturer - China

price: 4600.00 Dollar US$

1 - Brief introductions of QZ-2CS drilling rig

QZ-2CS type gasoline engine portable sampling drill is used for geological industrial and civil buildings, bridges, railway, highway, hydro power industry survey, geophysical exploration, advanced drilling and grouting hole drilling.

QZ-2CS drilling rig has the following features: compact structure, small volume, light weight, two gears, easy to move.

2 - Specifications of QZ-2CS drilling rig QZ-2CS drilling rig End hole diameter (mm) 32-91

Drilling depth(m) soil 91:10-15m

stone 91:5-10m

stone 75:10-15m

stone 60:15-20m

stone 46:20-30m

Drilling pipe diameter(mm) 30

Gasoline engine horse power(hp) 6(4.5kw) displacement(cc) 224

Dimension(l*w*h) 600*450*1900

Weight(kg) 95

3 - Configuration list of QZ-2CS

Item Parameter Unit Quantity

Gasoline core drilling rig QZ-2CS set 1

Drilling pipe 30*1500 pc 6

Drilling pipe 30*800 pc 14

Pipe joint 38 pc 20

Reducing nipple 58/38 pc 2

Core barrel 58*800 pc 1

Core barrel 58*1500 pc 1

Alloy bit 60 pc 1

Diamond bit 60 pc 1

Reducing nipple 73/38 pc 2

Core barrel 73*800 pc 1

Alloy bit 75 pc 1

Diamond bit 75 pc 1

Three-wing bit 75 pc 1

Safety clamp pc 1

Oil seal 30*50*10 pc 1

Water seal Y 30*50*10 pc 4

Pipe wrench 18 pc 2

Monkey wrench pc 1

Hole snap ring clamp pc 1

Shaft snap ring clamp pc 1

Clamp pc 1

Cross screwdriver pc 1

Control wheel pc 1

Hex wrench pc 1


Company Contact:


  • Phone: 18865479502

  • Address: No.47,Jinyu Road,Jining City,Shandong Province,China, jining , China , China

  • Email: Email


Published date: December 15, 2018
