Fy150 Crawler Type Pneumatic Drilling Rig - China
price: 12600.00 Dollar US$
1 - The applications of FY150 crawler type gasoline engine drilling rig
civil engineering drilling
geothermal drilling
drilling with large diameter and deep drilling footage
It’s fast, flexible and efficient.
2 - The specifications of FY150 crawler type gasoline engine drilling rig
Model FY150
Gross weight t 3.0
External dimension mm 3400*1450*2000
Aperture mm 130-219
Drilling depth m 150
Feed stroke mm 3000
Travel speed km/h 2
Grade ability max.
25°
Rising height from ground mm 250
Wind pressure mpa 1.45-2.5
Air consumption m³/min 15-27
Engine power kw 37-55
Rotary speed rpm 38-55
Rotation torque n.
m 4000-5000
Company Contact:
- Posted By: Shandong Master Machinery Group Co.,Ltd.
- Phone: 18865479508
- Address: No.47,Jinyu Road,Jining City,Shandong Province,China, JINING , China , China
- Email:
- Website: http://www.sdjujiang.com
Published date: October 24, 2018
- Business Description: Master Group Co., Ltd. is dedicated to providing the drilling rig and pile driver for engineering and mining construction.
As a active response to the Belt and Road Initiative, We have took numerous efforts to go abroad.
Our products have been sold to Europe, CentralAsia, Southeast Asia, Africa and dozens of countries and regions.
We focus on providing innovative products and services that meet or exceed the expectations of our global customers while complying with safety and regulatory requirements.
We are a leading company in the drill rig industry in China.
We have established solid relationship with several universities, research laboratories, designing institutes and prospecting institutes.
And we have participated in a number of national key projects and earned our reputation.
Our Companys “HuaxiaMaster” has become a well-known brand in China.
