Huaxiamaster Sale Full Hydraulic Pneumatic Well Drilling Rig Fy 200 Crawler Drill - China
price: 26000.00 Dollar US$
1 - The applications of FY200 crawler pneumatic water well drilling rig
·drilling with large diameter
·deep drilling footage ·civil engineering drilling
·geothermal drilling
·fast, flexible and efficient.
2 - The specifications of FY200 crawler pneumatic water well drilling rig Model FY200
Aperture mm 140-325
Drilling depth m 200
Feed stroke mm 3000
Travel speed km/h 2.5
Grade ability max.
30°
Gross weight t 4.6
Dimension mm 3800*1600*2450
Rising height from ground mm 250
Wind pressure mpa 1.7-3.0
Air consumption m³/min 17-35
Engine power kw 65
Rotary speed rpm 50-70
Rotation torque n.
m 5000-6500
