Rocky Core Electric Rig For Mining Tunnel Rock Anti Explosion Exploration Drilling Equipment - China

price: 100.00 Dollar US$

Rocky Core Electric Rig For Mining Tunnel Rock Anti Explosion Exploration Drilling Equipment

Products Photos Catalog Rocky Core Electric Photos Catalog

1 - Brief introductions of KHYD110 electric rock drilling rig

·The electric rock drilling rig can be fitted with drill stand, and can be drilled horizontally or upward in any direction.

·In order to prolong the service life of the drill bit and improve the working conditions of the operator, wet drilled water can be used to discharge the powder and screw blade drills can also be used for dry draining.

·In the operation of electric motor rock drilling rig, we only need to operate the handwheel, and the electric motor rock drilling rig can advance itself and return quickly.

2 - Specifications of KHYD110 electric rock drilling rig

Model Unit KHYD110

Rated output power of motor kw 5.5

Rated voltage of motor v 380/660

Rated frequency of motor hz 50

Rated current of motor a 11.6

Motor speed r/min 1440

Motor phase number three phase communication

Rated working mode continuity

Drilling speed mm/min 280

Speed of return m/min Borehole diameter mm 42-80(rock)

Hardness range protodikonov`s scale of hardness f<10

Maximum drilling depth m 20(rock)


Company Contact:


  • Phone: 8619806265526

  • Address: Wu taizha road, guanhe street,, Jining , Shandong , China

  • Email: Email


Published date: September 24, 2019

  • Business Description: Group for a long time in line with the giants of masters of "the spirit of craftsman, creates quality" concept of enterprise development, challenge pragmatic development, now has developed into a collection of research and development design, manufacture and market sales in the integration of many company joint operation of collectivization, giant group members have jining machinery research institute, shandong machinery manufacturing co., LTD., the giants of the giants and huge machinery co., LTD., shandong province, China, etc.
