Sjdy 3 Three Phase Electric Full Hydraulic Water Well Drilling Rig - China

price: 100.00 Dollar US$

SJDY-3 three-phase electric full hydraulic water well drilling rig is suitable for soil layer, sand layer and a small amount of rock layers.

It is mainly used for drilling civil water wells, irrigation wells, ground source heat pump air conditioning wells, precipitation wells, small foundation piles, and sound measurement tube and so on.

SJDY-3 three-phase electric hydraulic water well drilling rig is light and compact with high hole-forming speed and low noise.

The machine automatically unloads the drill pipe and is easy to move.

2 - Parameters of SJDY-3 three-phase electric full hydraulic water well drilling rig

Drilling depth m 0~120

Maximum opening hole diameter mm 500

Final hole diameter mm 150~500

Drill pipe specifications mm Φ60*1500

Rated voltage V 380

Rated power kw 7.5

Spindle torque N.

m 500

Rated lifting force kn 10

Lift stroke mm 900

Rig weight kg 320

Number of operators 2

(Please specificy if order screw bracing, wheel and tow bar)


Company Contact:


  • Phone: 8619806265526

  • Address: Wu taizha road, guanhe street,, Jining , Shandong , China

  • Email: Email


Published date: July 11, 2019

  • Business Description: Group for a long time in line with the giants of masters of "the spirit of craftsman, creates quality" concept of enterprise development, challenge pragmatic development, now has developed into a collection of research and development design, manufacture and market sales in the integration of many company joint operation of collectivization, giant group members have jining machinery research institute, shandong machinery manufacturing co., LTD., the giants of the giants and huge machinery co., LTD., shandong province, China, etc.
