Xy 180 Hydraulic Core Drilling Rig - China

price: 5800.00 Dollar US$

Xy 180 Hydraulic Core Drilling Rig

Products Photos Catalog 180 Hydraulic Core Photos Catalog

1 - Applications of XY-180 core drilling rig

The XY-180 drilling rig is designed on the basis of the XY-1A drill.

It is a low speed and high torque portable drilling machine with oil pressure.

This drill rig is suitable for engineering geological survey of railway, hydropower, traffic, bridge, dam foundation and other buildings, geological core drilling and physical investigation, drilling holes for small holes and blasting holes, a small water well drilled.

2 - Parameters of XY-180 core drilling rig

Drilling depth(m) 180/150/120/90/70/30

Borehole diameter(mm) 75/91/110/130/150/300

Maximum opening diameter(mm) 375

Drill pipe diameter(mm) 42/50

Spindle Speed (r/min) 71/142/310/620

Spindle Stroke(mm) 450 Upgrading Ability (KN) 15

Diameter of steel wire(mm) 12

Type gear pump

Model YBC-12/80

Rated pressure (MPa) 8

Rated speed (r/m) 1500

Displacement(ml/r) 8

Power supply ZS1115 diesel engine and 15kw motor


Company Contact:


  • Phone: 18865479508

  • Address: No.47,Jinyu Road,Jining City,Shandong Province,China, JINING , China , China

  • Email: Email


Published date: October 31, 2018

  • Business Description: Master Group Co., Ltd. is dedicated to providing the drilling rig and pile driver for engineering and mining construction.

    As a active response to the Belt and Road Initiative, We have took numerous efforts to go abroad.

    Our products have been sold to Europe, CentralAsia, Southeast Asia, Africa and dozens of countries and regions.

    We focus on providing innovative products and services that meet or exceed the expectations of our global customers while complying with safety and regulatory requirements.

    We are a leading company in the drill rig industry in China.

    We have established solid relationship with several universities, research laboratories, designing institutes and prospecting institutes.

    And we have participated in a number of national key projects and earned our reputation.

    Our Companys “HuaxiaMaster” has become a well-known brand in China.
