Xy 180 Hydraulic Core Drilling Rig Price - China
price: 10500.00 Dollar US$
1 - Applications of XY-180 core drilling rig
The XY-180 drilling rig is designed on the basis of the XY-1A drill.
It is a low speed and high torque portable drilling machine with oil pressure.
This drill rig is suitable for engineering geological survey of railway, hydropower, traffic, bridge, dam foundation and other buildings, geological core drilling and physical investigation, drilling holes for small holes and blasting holes, a small water well drilled.
2 - Parameters of XY-180 core drilling rig
Borehole diameter(mm) 75/91/110/130/150/300
Drilling depth(m) 180/150/120/90/70/30
Maximum opening diameter(mm) 375
Drill pipe diameter(mm) 42/50
Spindle Speed (r/min) 71/142/310/620
Spindle Stroke(mm) 450 Upgrading Ability (KN) 15
Diameter of steel wire(mm) 12
Type gear pump
Model YBC-12/80
Rated speed (r/m) 1500
Rated pressure (MPa) 8
Displacement(ml/r) 8
Power supply ZS1115 diesel engine and 15kw motor
Company Contact:
- Posted By: Shandong Master Machinery Group Co.,Ltd.
- Phone: 18865479502
- Address: No.47,Jinyu Road,Jining City,Shandong Province,China, jining , China , China
- Email:
- Website: http://www.sdjujiang.com
Published date: January 16, 2019
- Business Description: Shandong Master Machinery Group Co., Ltd. is located in Jining city, Shandong Province , which is known as "The hometown of Confucius, formal state" reputation .
Company east to “ Oriental holy city”of qufu, west to “hero”of liangshan, “qilu graceful” weishan lake in the south, "wuyue exclusive" Tarzan in the north, The martial arts are prosperous, and the people are geeky.
convenient transportation like Jining airport, beijing-shanghai high-speed railway, lunan high-speed railway, beijing-taiwan expressway, zhanlan high-speed crisscross, , communication developed.
Shandong Master Machinery Group Co., Ltd. as parent company and head office hold the spirit of "delivering the spirit of craftsman and the quality of the great craftsman" for a long time , Pragmatic development will strengthen our progress.
Nowadays, it has developed into a collectivized enterprise integrating r&d design, production processing and marketing.
The group company mainly provides solutions for engineering and mine construction.
With high quality products, good service and honest reputation, our company has established a solid material supply relationship with several universities, research institutes, design institutes and reconnaissance institutes.
And stand out from a large number of national key project construction projects , The market performance is among the best in the industry.
The group company actively responds to the national "One Belt And One Road" policy to go abroad.
Drilling rig products are now sold to many countries in Europe, central Asia, southeast Asia and Africa.
Our company's independent brand "HuaxiaMaster" has become a well-known brand for customers.
It is a pleasure to have friends coming from afar.
We warmly welcome friends from all walks of life to visit our company and work together to create a better tomorrow.
