Xy 200 Hydraulic Water Well Drilling Rig - China

price: 5700.00 Dollar US$

Xy 200 Hydraulic Water Well Drilling Rig

Products Photos Catalog 200 Hydraulic Water Photos Catalog

1 - The applications of XY-200 drilling machine

Water well, field irrigation well, engineering water well, precipitation well and so on; geological survey, geophysical exploration, road and high-rise building foundation exploration, wells, blasting holes and other drilling projects.

2 - The Specifications of XY-200 drilling machine

Maximum opening hole diameter 400mm

Drilling depth 200m

End hole diameter 75mm

Drilling angel 90-75°

Dimension 2.75X0.95X1.60m

Drilling pipe diameter 50mm

Weight without power 760kg

Spindle

Spindle rotation speed 71/142/310/20r/min

Spindle stroke 450mm

Winch

Maximum lifting weight (single rope) 2008kb

Lifting speed 17/35/75/160rm/s

Wire-rope diameter: 13mm

Roll capacity 35mm

Mud pump

Type: horizontal single cylinder double action flow：180L/min

Maximum pressure 1.5mpa

Working pressure 0.7mpa

Inlet pipe diameter 50mm

Outlet pipe diameter 45mm

Power

Diesel 20hp

Rated speed 2200r/min

Electric motor 15kw

Rated speed 1460r/min


Company Contact:


  • Phone: 18865479508

  • Address: No.47,Jinyu Road,Jining City,Shandong Province,China, JINING , China , China

  • Email: Email


Published date: October 23, 2018

  • Business Description: Master Group Co., Ltd. is dedicated to providing the drilling rig and pile driver for engineering and mining construction.
