Zlj350 Grouting Recommencement Drilling Rig - China

price: 3600.00 Dollar US$

Zlj350 Grouting Recommencement Drilling Rig

Products Photos Catalog Zlj350 Grouting Photos Catalog

1 - The brief introductions of ZLJ350 ZLJ 350 grouting reinforcement drilling machine is mainly used for grouting reinforcement hole.

ZLJ350 drilling machine work for under mine, tunnel, subway, slope support.

The machine can work different angles of grouting reinforcement and drilling hole.

This drill rig adopts mechanical drive, hydraulic feed with small size, light weight, The rig is reliable and convenient to operate.

2 - The specifications of ZLJ350 Drilling diameter 50-113mm

Drill rod caliber 42mm

Noncoring bit 50-113mm

Core bit 56-113mm

Vertical rated speed 340 /192/112 r/min

Vertical shaft torque rating 130/ 230 /400 n.

m

Main shaft angle 0-360

Spindle stroke 400mm

System pressure rated 8mpn

Feed force 9kn

Elevating power 12kn

Winch lifting capacity 7.35kn

Capacity of drum 26.8m

Diameter of wire rope .

85mm

Oil pump type YBC-12/80

Motor power 5.5kw

Dimension 1230*630*1280mm

Total weight 430kg


Company Contact:


  • Phone: 18865479508

  • Address: No.47,Jinyu Road,Jining City,Shandong Province,China, JINING , China , China

  • Email: Email


Published date: October 31, 2018

  • Business Description: Master Group Co., Ltd. is dedicated to providing the drilling rig and pile driver for engineering and mining construction.

    As a active response to the Belt and Road Initiative, We have took numerous efforts to go abroad.

    Our products have been sold to Europe, CentralAsia, Southeast Asia, Africa and dozens of countries and regions.

    We focus on providing innovative products and services that meet or exceed the expectations of our global customers while complying with safety and regulatory requirements.

    We are a leading company in the drill rig industry in China.

    We have established solid relationship with several universities, research laboratories, designing institutes and prospecting institutes.

    And we have participated in a number of national key projects and earned our reputation.

    Our Companys “HuaxiaMaster” has become a well-known brand in China.
