200l Evacuated Tube Solar Pool Heater - China
price: check with company for price
200L Compact Non Pressurized Vacuum Tube Solar Water Heater Thermosiphon System Working principle: Larger proportion of hot water than cold water, cold water flows downward and hot water goes upward.
Water will be heated continuously between water tank and vacuum tube.
Hot water always floats on cold water.
Hot water flows to water tank from vacuum tubes.
Proportion cold water flows to vacuum tubes from water tank .
Certificate: CE Specifications: Instant Solar Water Heater Vacuum Tube 1 - Advanced technique 2 - Corrosion resistant 3 - Delivery Fast, OEM/MOQ Acceptable - - - - Solar Hot Water Storage Tank | Material of outer tank | Galvanized Steel | Material of inner tank | Food grade stainless steel 304-2B | Tank insulating layer | 50 mm thickness with high density polyurethane foam | Welding | Argon arc welding | Tank structure | Inlet, Outlet, Drainage & Air Vent or Customized | Solar Vacuum Tube | Tube structure | All-glass double deck co-axial structure | Glass material | High borosilicate 3.3 glass | Outer tube diameter and glass thickness | 58 0.7mm; Glass thickness 1.6 0.15mm | Inner tube diameter and glass thickness | 47 0.7mm; Glass thickness 1.6 0.15mm | Tube size | Tube size | Absorptive coating property | Structure | Cu / SS-ALN(H) / SS-ALN (L) / ALN | Sediment method | Three targets magnetron sputtering plating | Specific absorption | 0.93-0.96(AM1.5) | Emission ratio | 0.04-0.06(800C 50C) | Solar irradiation for obtaining a preset water temperature | =58 H 4.7MJ/m | H=3.7-4.2MJ/m | Vacuum tightness | 5.0 10 -3 Pa | Idle sunning property parameters | 260-300 m .
C/KW | Average heat loss coefficient | ULT=0.4~0.6W/(M 2.0 C) | Resistant Hail | 25mm | Life span | 15 years | Solar System Bracket | Bracket material | Galvanized Steel | Bracket angle | 0-45 degrees | Fastening pieces | Stainless Steel Nut Bolt | Thickness | 1.5mm | - - - - Features: 1 - Easy installation; 2 - Reliable and efficient ; 3 - Corrosion resistant materials; 4 - Stable solar conversion during the day; 5 - Most efficient and most economic model; 6 - Ideal for many solar water heating applications; 7 - Economic goods surpass their money with good efficiency; 8 - Aluminum frame, Galvanized steel frame, or color steel frame; 9 - Simple structure and working principle but the most economical.
- - - - Payment Terms | L/C, T/T | Minimum Order | 2 sets | Lead Time / Delivery Time | 15 Day(s) | Sample Available | YES | Delivery Details | after receipt of payment | Port of Lading | Ningbo / Shanghai | Shipping | by sea | Packing | export carton | Target Market(s) | Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia | - - - -
Company Contact:
- Phone: 86-135-11388384
- Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China
- Email:
Published date: April 19, 2018
- Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.
As an experienced company, we can provide the perfect solution for Solar Thermal System.
Our products include solar water heater, solar collector and accessories.
