300l Split Solar Water Heater For House - China

300L White Active High Temperature Copper Coil Split Solar Water Heater for House Used Application Mainly for family shower/bath How to choose Choose the item according to the capacity, and choose the capacity according to the people quantity in your family, one adult shower need about 50L water.

STRUCTURE of Split Pressurized Solar Water Heater The split solar water heater is composed by solar heat collector, cylinder water tank and working station( pump station).

1 - Collector: heat pipe, or U pipe 2 - Tank: pressure tank, 100L-1500L 3 - Work station Working principle 1 - The collector absorbs solar energy and transmits it to the water tank through circulation .

2 - When the temperature of the collector reaches the set value, the controller starts the circulation pump automatically.

3 - The circulation pump makes heat-conducting liquid circulate automatically.

4 - The heat-conducting liquid transfers heat to water by lower heat exchanger in the water tank.

5 - When the temperature difference between solar collector and tank doesn't reach the set value, the circulation pump will be shut automatically .

6 - In case the temperature of the water tank does not reach Tmax, Electric Heating Element will start to work automatically.

Features 1 - Strong hydraulic pressure makes your bathe more comfortable.

2 - module design, arbitrary combination, harmonious with the building perfectly.

3 - Intelligent controlling and multiple functions.

4 - Arbitrary combination with structure of your beautiful constructions.

5 - Separate installation conveniently.

6 - workable at anytime and enjoyable.

7 - Working with assistant resource.

8 - Full set of original equipment, the life time will be much longer to ensure better using.

Specification - - - - Name | Split pressurized solar water heater | Material of out manifold | 0.31-0.55mm thickness color steel/ fluorine carbon steel | Material of inner tank | Food grade 1.2-2.0 mm thickness SUS304 stainless steel | Material of outer tank | colour steel or stainless steel | Inlet and outlet hole | Male G3/4 | Max pressure | 0.6 Mpa | Solar collector tube | 3.3 Borosilicate glass with SS-ALN(L)/ALNor CU/SS/ALN coating | Thickness of glass tube | 1.6mm | Vacuum tube tightness | P0.005 Pa | Absorption | as=0.93-0.96(AM1.5) | Emission ratio | h=0.04-0.06(80C5C) | Idle sunning property parameters | Y=220~260m2 - C/KW | Average heat loss coefficient | ULT=0.6~0.7W/(m2 - C) | Bracket: | 2.0mm thickness aluminum alloy | Welding: | Argon arc welding | Fastening pieces: | Made of stainless steel screw | Tank capacity | 100L, 150l, 200L, 300L, 500L, 800L, 1000L | Solar collector | 10/12/15/18/20/24/30 tubes | OEM | Provide | Working station | SP116, SP228 | Heat exchanger length | 18m | - - - - - - - - Split Pressurized Solar Water Heater | Model | Tube quantity | Tank Capacity (Liter) | Copper coilers length(m) | Packing size (CBM) | Loading quantity(sets) | 20'GP | 40'GP | 40'HQ | With double coilers in the water tank(35-50m copper coil as heat change material) | PT2-100 | 10 | 100 | 10+10 | 0.587 | 48 | 98 | 115 | PT2-150 | 15 | 150 | 12+10 | 0.670 | 41 | 85 | 101 | PT2-200 | 20 | 200 | 15+10 | 0.860 | 32 | 67 | 79 | PT2-250 | 25 | 250 | 18+12 | 1.070 | 25 | 54 | 63 | PT2-300 | 30 | 300 | 18+12 | 1.210 | 23 | 47 | 55 | PT2-400 | 40 | 400 | 22+15 | 1.466 | 20 | 40 | 47 | PT2-500 | 50 | 500 | 25+15 | 1.534 | 19 | 38 | 45 | PT2-600 | 60 | 600 | 30+18 | 2.330 | 12 | 24 | 30 | PT2-700 | 70 | 700 | 35+18 | 2.780 | 10 | 20 | 25 | PT2-800 | 80 | 800 | 40+20 | 3.065 | 9 | 17 | 22 | PT2-1000 | 100 | 1000 | 50+30 | 3.975 | 7 | 14 | 18 | - - - - FAQ Payment terms: T/T, L/C, Paypal, Western union all support.

Delivery time: Sample order 3 working days, Container order 10 working days.

Minimum order quantity: 1 PC Guarantee period: 8 years OEM service: Support (Print logo on carton for free)
