Ce Approved Solar Energy Water Heater 150l - China

150L Integrated Pressured CE Approved Enamel Tank Heat Pipe Solar Water Heater 80L-500L compact heat pipe solar water heater stainless/galvanized solar hot water heater Specifications: 1) inner tank adopt SUS304-2B, thickness 1.5mm, Withstand pressure of 6 Bar.

2) outer tank: SUS-201 stainless/galvanized steel, thickness: 0.31mm.

3) bracket: SUS-201 stainless/galvanized steel, thickness: 1.2mm.

4) vacuum tube: AL-SS/CU with heat pipe; 5) insulation layer: 55mm polyurethane.

Primary competitive advantage: 1) CE, CCC, ISO9001 approval 2) Competitive Price 3) Prompt delivery 4) Environmental protection 5) Small order and OEM order accepted.

- - - - Product Model | Tubes | Tank Capacity | Absorbing Area | Weight | Dimension (LWH) | Qty.

per 20FT/40FT/40HQ | 470-1800/58-12 | 12pcs | 100L | 0.92m2 | 63KGS | 1830*1210*1600 | 52/ 104 / 126 | 470-1800/58-15 | 15pcs | 125L | 1.14m2 | 78KGS | 1830*1450*1600 | 43 / 86 / 104 | 470-1800/58-18 | 18pcs | 150L | 1.37m2 | 93KGS | 1830*1690*1600 | 35 / 70 / 85 | 470-1800/58-20 | 20pcs | 165L | 1.52m2 | 103KGS | 1830*1850*1600 | 32 / 64 / 78 | 470-1800/58-24 | 24pcs | 200L | 1.83m2 | 125KGS | 1830*2170*1600 | 27 / 55 / 67 | 470-1800/58-30 | 30pcs | 250L | 2.29m2 | 156KGS | 1830*2650*1600 | 23 / 46 / 55 | - - - - Description: This is pressurized system, with tank and collector combined, so we call it integrated pressurized system.

The design of this system is indirect heating system.

The tap water piping is connected directly to the system, and water is feed automatically by the water pressure.

The vacuum tubes absorb the sun energy and transfer the heat to the tank through the copper heat pipe inside the tube, then water inside the tank is gradually heated.

This system includes the MG anodes, which is used for anti-corrosion, and electric element, which is used when theres no enough sun.

And it also includes the P/T safety valve.

So if the tank is overheated and water pressure exceeds 6 bar, the P/T valve will open automatically to protect the tank.

This system has now been approved to be one of the most effective system, so this is more and more popularly used in the world.

Accessories: 1 - Electric heater: 1500W-2000W/220V-2 30V; 2 - Intelligent controller: SR609(esp.

for integrative pressurized type); 3 - P/T valve (pressure & temperature): WAY-20, 0.7MPa; 4 - Magnesium rod: diameter 20mm, length 23 cm, copper connector; 5 - Temperature sensor; 6 - Air vent valve; 7 - Vacuum valve; 8 - Check valve.

Additional Information: - - - - Payment Terms | T/T | Minimum Order | 10 | Lead Time / Delivery Time | 10 Day(s) | Sample Available | YES | Delivery Details | 15 days when we get your advanced payment | FOB Port | Ningbo, Shanghai | Loading Info | shipping | Packing Info | exported standard cartons | Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe | - - - - FAQ: 1 - What is your Delivery Time? LCL order: 10days.

Full container order: 15days.

2 - What is your Guarantee Time? 6 years; Provide you with some accessories, they are free for you.

3 - Can you accept OEM and ODM ? YES, printing your LOGO on the product and package, it's free.

4 - What is your payment term? We accept T/T or L/C, Western Union and Paypal.

5 - What is your MOQ? 4 sets 6 - Low do you pack? LCL order in plywood case Full container order in high quality export carton 7 - What is your FOB port? We accept FOB Shanghai, Ningbo, Shenzhen, Guanagzhou, Qingdao etc.

8 - What is your monthly production capacity? 1000 sets 9 - What is your shipping term? By sea/Air/Rail/Truck 10 - Do you any additional services? YES! We offer free spares according to your order quantity.

Such as Vacuum Tube, tube holders, dusting rings, silicon rings, screws etc.

And we can offer logo design, Products Advertising Design etc services free.

Company Contact:

• Posted By: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD.

• Phone: 86-135-11388384

• Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China

• Email:

• Website: https://www.thermalsolarwaterheater.com

• Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.

  As an experienced company, we can provide the perfect solution for Solar Thermal System.

  Our products include solar water heater, solar collector and accessories.
