Flat Plate Solar Thermal Collector High Efficiency - China
price: check with company for price
Slope Roof High Efficiency Pressurized Heat Pipe Thermal Solar Collector For Solar Thermal Heating Description: Solar heater, solar water heater, solar hot water heater, solar water heater system, solar water heater project, solar collector, evacuated tube solar collector, vacuum tube solar collector, heat pipe solar collector - - - - Overall Height | 185mm | Overal Width | 1475mm | Overal Length | 1985mm | Aperture Area | 1.68m | Gross Area | 2.88m | Peak Heat Output | 1233w | - - - - Evacuated tube solar collectors are suitable for both residential and commercial applications.
The design of the solar collector is a culmination of nearly 10 years of feedback from installers and solar professional all over the world and aims to meet their requirements.
Working Principle: Step 1: The absorber coating on the inner glass tube absorbs sunlight and converts it into heat.
Step 2: Steam forms inside heat pipe which transfers heat rapidly up to the manifold.
Step 3: A pump circulates water or heat transfer fluid through the header pipe, carrying heat back to the storage tank.
Gradually throughout the day the tank is heated up.
Product Specifications & Details: Model: Heat Pipe Solar Collector Flow channel: Material of TP2, 0.9MM in thickness Head box: Aluminum alloy Insulation layer: Rock wool/ PU layer Heat pipe: 24mm for condensor, material of TU1 copper Frame: Aluminum sheet 1.8mm Vacuum tube: QB-CU-AL-NAL-58*1800, 10, 12, 15, 18, 20, 24, 25, 30 tubes Silicon ring: High polymer silicon rubber Solar collectors for water material specification: - - - - Description | pressurized solar collector | Material of out manifold | Aluminum Alloy | Material of inner tank | Copper Header Pipe | Inlet and outlet hole | Male G3/4 | Max pressure | 0.6 Mpa | Solar collector tube | 3.3 Borosilicate glass with N/Al coating | Thickness of glass tube | 1.6mm | Vacuum tube tightness | P0.005 Pa | Absorption | as=0.93-0.96(AM1.5) | Emission ratio | h=0.04-0.06(80C5C) | Idle sunning property parameters | Y=220~260m2 - C/KW | Average heat loss coefficient | ULT=0.6~0.7W/(m2 - C) | Bracket: | Aluminum Alloy/ Galvanized Steel | Welding: | Argon arc welding | Fastening pieces: | Made of stainless steel screw | - - - - Specification of vacuum tube: - - - - Item No.
| Specification | Qty.
of solar tubes | Diameter of solar tube | Length of solar tube | Absorber area | Dimension | PT125-1800/58-15 | 15pcs | 58mm | 1.8M | 1.2 | 1060*2000 | PT125-1800/58-20 | 20pcs | 58mm | 1.8M | 1.6 | 1410*2000 | PT125-1800/58-30 | 30pcs | 58mm | 1.8M | 2.4 | 2110*2000 | - - - - Tips Considering the economics of a solar water heating system Evaluate your site's solar resource Determine the correct system size Determine the system's energy efficiency Packaging & Delivery Packaging Details: 1 - Standard export packing for FCL order.
2 - Special packing for LCL order.
Delivery Detail: 10-15 days after receipt of deposit.
Company Contact:
- Phone: 86-135-11388384
- Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China
- Email:
Published date: April 19, 2018
- Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.
As an experienced company, we can provide the perfect solution for Solar Thermal System.
Our products include solar water heater, solar collector and accessories.
