Flat Plate Water Heater High Efficiency - China

300L Integrated Pressurized Copper Coating High Efficiency Flat Plate Solar Water Heater Detailed Product Description Flat-plate collectors are the most common solar collectors for use in solar water-heating systems in homes and in solar space heating.

A flat-plate collector consists basically of an insulated metal box with a glass or plastic cover (the glazing) and a dark-colored absorber plate.

Solar radiation is absorbed by the absorber plate and transferred to a fluid that circulates through the collector in tubes.

In an air-based collector the circulating fluid is air, whereas in a liquid-based collector it is usually water.

Flat-plate collectors heat the circulating fluid to a temperature considerably less than that of the boiling point of water and are best suited to applications where the demand temperature is 30-70C (86-158F) and/or for applications that require heat during the winter months.

Flat collectors can be mounted in a variety of ways, depending on the type of building, application, and size of collector.

Options include mounting on a roof, in the roof itself, or free-standing.

Technical data of Flat Plate Solar Collector - - - - Name | Flat Plate Solar Collector | Outline area | 1.88 | Aperture area | 1.82 | Absorption area | 1.75 | Dimensions | 960*1960*80 | NW | 20/21kg | Capacity of cooper pipe | 1.7L | Transparent cover | Ordinary fabric surface tempered glass | Aperture rate | 91% | Thickness transparent cover | 3.6mm | Absorber | 0.4mm roller coating aluminum plate | Thickness of Frame | aluminum 0.35mm(915*1915) | Heat absorption rate | 912% | Emission rate | 92% | Welding tech between copper pipe and absorber | laser welding from Bluetech (spot welding double pitch 4mm) | Head tubes | 22*1 mm aluminum pipe | Riser tubes | Grid type10*1mm | insulation materials | 30mm glass wool | Insulation thickness | 20mm | alloy frame material | Aluminum-magnesium(thickn ess 1mm) | Frame color | black | Back plate materials | Galvanized sheet | Back plate thickness | 0.3mm | Sealing material | Silicon ring | Heat Medium | Pure water or glycol medium | Testing pressure of inner circulating | 0.9Mpa | Working pressure of inner circulating | 0.6Mpa | operation temperature | 170C | - - - - Packing: LCL( Less than Container Load ): Wooden case FCL( Full Container Load ): Export carton Delivery: Usually, it is 10 Working days after receiving deposit or original L/C.

FAQ: -Can you provide FREE SAMPLES? Sorry, you have to pay it first, but we'll cut the costs in your next order(20GP).

-Can you accept OED/ODM? Yes, we can paint the logo on the product and package if you need, it is free for containers.

-What is your GUARANTEE TIME? 10 years for vacuum tubes, 5 years for frame, 3 years for water tank, 1 year for other parts.

-What is your PAYMENT TERM? T/T, L/C -Do you have other ADDITIONAL SERVICE? YES.

We provide free spares according to your order, such as vacuum tubes, tube holders, dust rings, seal rings, screws etc.

Also, we can provide logo design free if you have an order at least 20 feet container.
