Industrial Solar Water Heater 250l - China

Natural Circulation 250L Colored Steel Flat Plate Thermal Solar Water Heater With Clean Water Pollution Working principle: There are two layers water tank, heat transfer fluid circulated between water tank and flat plate collectors naturally.

Then it will be heated and transfer energy to water in inner tank.

Hot water from this kind of solar water heater is pressurized.

It is easily installed on the house roof.

Advantages: 1 - Flat plate collectors with high weather-proof selective absorbing film from full-automatic magnetron sputtering production line developed by Bontel; 2 - Flat plate collectors with Bonding heat transferring technology and laser welding technology; 3 - Flat plate collectors with high quality low-iron tempered glass with surface treatment to get high transmittance and low emittance; 4 - Enamel inner tank with magnesium rod show excellent anticorrosion performance Feature: Special design for oversea market: special anodized aluminum alloy frame ensures handsome appearance and can bear high pressure without leakage.

50mm fiberglass insulation and EPDM seal strip to assure the solar collector can work under harsh or very cold temperature.

Operation temperature: -33C~120C.

Patterned tempered glass or low iron tempered glass (4mm thickness) is not broken easily with high transmission and low emission.

Blue/Black chrome coating has absorption rate to ensure excellent efficiency.

Description Of Flat Plate Solar Water Heater - - - - Model No.

| PT-01 | PT-02 | PT-03 | PT-04 | Dimension LWT(mm) | 2000106070 | 2000100080 | 2000100090 | 20001000100 | Gross Area(m2) | 2.0 | 2.0 | 2.00 | 2.00 | Efficiency Area (m2) | 1.82 | 1.82 | 1.82 | 1.82 | Gross Weight of Collector(kg) | 473 | 55 3 | 47 3 | 55 3 | Transparent Cover | | Number of Cover(pc) | 1 | 1 | 1 | 1 | Dimension LW(mm) | 1975 975 | 1975 975 | 1975 975 | 1975 975 | Cover Material | Float Glass/Low-iron Glass | Float Glass/Low-iron Glass | Float Glass/Low-iron Glass | Float Glass/Low-iron Glass | Cover Thickness(mm) | 4 | 4 | 4 | 4 | Cover Transmission | 89%-91.4% | 89%-91.4% | 89%-91.4% | 89%-91.4% | Absorber | | Dimension LW(mm) | 1840 956 | 1840 956 | 1840 956 | 1840 956 | Material | Red Copper | Red Copper | Red Copper | Red Copper | Surface Treatment | Galvanized Chromium Coating | Blue Tech | Galvanized Chromium Coating | Blue Tech | Construction Type | Fin and Tube | Fin and Tube (Ultrasonic Welding) | Fin and Tube | Fin and Tube | Header Material | T2 Copper tube | Copper TP2 | T2 Copper tube | Copper TP2 | Header Tube Size(mm) | 25 1060 0.6 2pcs | 25 1060 0.6 2pcs | 25 1060 0.6 2pcs | 25 1060 0.6 2pcs | Rise Material | T2 Copper tube | Copper TP2 | T2 Copper tube | Copper TP2 | Rise Tube Size(mm) | 10 1886 0.5 8pcs | 10 1886 0.5 8pcs | 10 1886 0.5 8pcs | 10 1886 0.5 8pcs | Fill Capacity | 1.8L Including Header Pipe | 1.8L Including Header Pipe | 1.6L Including Header Pipe | 1.8L Including Header Pipe | - - - - Our Service For YOU Pre-sale Service 1 - Sample can be offered with sample charge and courier fee by buyer's side.

2 - We have full stock, and can deliver within short time.

Many styles for you to choose.

3 - OEM and ODM order are accepted, Any kind of logo printing or design are available.

4 - Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you 5 - All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.

6 - We have rich experience of design, manufacture and sell solar water heater, we cherish every order from our honor.

After you choose 1 - We will count cheapest shipping cost and make invoice to you at once.

2 - Check quality again, then send out to you at 1-2 working day after your payment, 3 - Email you the tracking no, and help to chase the parcels until it arrive you.

After-sale service 1 - We are very glad that customer give us some suggestion for price and products.

2 - If any question, please contact with us freely by E-mail or Telephone.
